Small Size Gimbal Electro Optical Tracking System Light Weight Affordable Usv
Small Size Gimbal Electro Optical Tracking System Light Weight Affordable Usv
Small Size Gimbal Electro Optical Tracking System Light Weight Affordable Usv
Small Size Gimbal Electro Optical Tracking System Light Weight Affordable Usv
Specifications
Brand Name :
JOHO
Model Number :
JHP103-M145B
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Supply Ability :
100units/Year
Delivery Time :
2 months after payment
Packaging Details :
Standard Packing
Function :
Searching, Observation, Tracking and Positioning
Type :
Visible Light Single Sensor
Application :
Navigation, Surveillance, Rescue
Customized :
Support Customized
Platform :
Two-axis
Detector :
1/2.8" CMOS
Pixel :
1920x1080
Focal :
35mm
Weight :
3.8kg
Description

JHP103-M145A Small Size Light Weight Affordable Gimbal for USV

Features and Function

  • Flexible sensors for various tasks
  • Small size, light weight and low power consumption
  • Two-axis stable, high precision gyroscope and servo control system realize full coverage reconnaissance.
  • Network communication interface. Wireless communication enables the ground station control framework and supports video/image return.
  • IP66, shock and vibration resistance, even in harsh environments can ensure a longer service life.

Technical Specification

JHS103-M145A Small Size and Affordable Gimbal
Model A: Thermal Camera
Detector Uncooled FPA Pixel 640×512
Spectral band 8μm~14μm Focal length 35mm
Model B: Day Light Camera
Detector 1/2.8" CMOS, 23x Resolution 1920×1080
System Parameter
Azimuth 360°continuous Elevation -20°~ +75°
Stabilization ≤0.5mrad Protection IP67
Power supply DC 24V/3A Power consumption ≤30W
Dimension Φ138m×224mm Weight ≤4kg
