2 Finger Pneumatic Gripper, Long Stroke TPL
2 Finger Pneumatic Gripper, Long Stroke TPL
Specifications
MOQ :
1
Description
Product Introduction

Excellent performance

1. The TPL grippers have super long stroke and 4 pistons structure.

● Longer stroke to meet the requirements of special working conditions

● Unique four-piston structure, smaller volume, higher gripping force


2 Finger Pneumatic Gripper, Long Stroke TPL


Model and Technical Parameters

Model

Stroke per jaw [mm]

Closing/ opening force[N]

Weight [kg]

Recommended workpiece weight[kg]

Closing/ opening time[s]

Repeat accuracy [mm]

Protection class IP
TPL-40A 40 1790/1050 4.5 8.95 0.40/0.40 0.02 40
TPL-70A 70 4450/2940 9.1 22.25 0.70/0.70 0.02 40
