Specifications
Brand Name :
BOTO
Model Number :
BT-X
Certification :
CE ISO
Place of Origin :
China
MOQ :
1set
Price :
Negotiated
Payment Terms :
L/C, T/T
Supply Ability :
30 Set/Sets per Day
Delivery Time :
1-15 days,to be negotiated
Packaging Details :
wooden case
Dimensions of the working chamber D*W*H :
950×950×850 mm
Boundary dimension D*W*H :
1350×1400×2100mm
Power :
About 15KW
Voltage and frequency :
380V±10% 50HZ
Temperature range :
0℃~80℃
Temperature deviation :
±2℃(without the lighting on)
Humidity range :
30~98%R.H
Rainfall time :
1 to 9999 minutes, adjustable
Description

Xenon Lamp Weather Resistance Testing Chamber Aging Test Chamber

Product Description
Product Name
Xenon Lamp Test Chamber
Dimensions of the working chamber D*W*H
950×950×850 mm
Boundary dimension D*W*H
1350×1400×2100mm
Power
About 15KW;380V±10% 50HZ
Temperature range
0℃~80℃(Not within the measurement range)
Temperature deviation
±2℃(without the lighting on)
Humidity range
30~98%R.H
Humidity deviation
±2.5%R.H(humidity≥75%R.H) ±3%R.H(humidity≤75%R.H)(without the lighting on)
The type of light source
Water-cooled full solar spectral long arc xenon lamp (average service life of about 1200 hours)
Rainfall time
1 to 9999 minutes, adjustable
Rainfall cycle
1~240 minutes, adjustable interval
Spectral wavelength
290nm~1200nm
Xenon lamp power
1CW, 6KW (lifetime: 1600 hours)
Wavelength range of light source
290-1200nm
Irradiated area
About 7500cm²
Distance from arc center to sample holder
350~380mm
Rotating speed of sample rotating basket
≥1r/min(stepless speed regulation)
Illumination time
Continuous programmable control
Blackboard temperature
65 ℃ + 3 ℃ adjustable
Refrigeration mode
Mechanical refrigeration air-cooled or water-cooled

Company introduction

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

BOTO GROUP is a professional manufacturer of various kinds of testing equipment over 20 years. BOTO products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and applicable to all scientific research units, quality inspection institutions and academic fields.

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

BOTO deals with customers from more than 150 countries and regions. Meanwhile, we are committed to cooperate with different dealers in different countries and regions in order to offer better service. Our mission is to help every customers establish testing labs to ensure the quality of their products.

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Our company will continue to develop, innovate and keep faith. We combine with the international testing standards and the specific demands of customers that may establish a new banner in Chinese testing industry.

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Main market

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

The factory has the ability to calibrate, and the customer can also designate a third party organization to calibrate and issue a calibration report.

Production Process

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Production Details

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Factory Inspection
We control quality from the materials, electronic parts, controller,comppressor, solenoid valve, and many parts of the products.

Certification

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Cooperative partners

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

BOTO ADVANTAGE

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Customers photos

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Environmental Test Chambers Xenon Lamp Aging Test Chamber for Weather Resistance

Our Services

During the whole business process, we offer Consultative Selling service.

1) Customer inquiry process:

Discussing testing requirements and technical details, suggested suitable products to customer to confirm. Then quote most suitable price according to customer requirements.

2) Specifications customize process:

Drawing related drawings to confirm with customer for customized requirements. Offer reference photos to show the products appearance. Then, confirm the final solution and confirm final price with customer.

3) Production and delivery process:

We will produce the machines according to confirmed PO requirements. Offering photos to show production process.

After finish production, offer photos to customer to confirm again with the machine. Then do own factory calibration or third party calibration(as customer requirements). Check and test all the details and then arrange packing.

Deliver the products in confirmed shipping time and inform customer.

4) Installation and after sale service:

Defines installing those products in the field and providing after-sales support.
