0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Enligy
Price :
$2,999.00/Sets 1-99 Sets
Structure :
Fire Tube
Fuel :
Oil,Gas,Diesel,Propane,LPG,LNG
Output :
Steam
Dimension(L*W*H) :
800*760*2180 mm
Weight :
350KG
Year :
2020
Key Selling Points :
Energy saving
Keywords :
lpg steam generator,machine steam boiler
Design fuel :
Oil,Gas,Diesel,Propane,LPG,LNG
Application :
Textile
Thermal efficiency :
96%--98%
Steam Capacity :
100kg/h
Rated working pressure :
0.7Mpa(7bar)
Steam temperature :
171
Voltage :
380V/50Hz
Description

0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Vertical Lpg Diesel Gas Fired Steam Boiler Steam Generator 100kg/H China Supplier Manufacturer For Textile Laundry Clean

Comprehensive Introduction
The gas steam generator produces pure steam by firing gas (including natural gas,liquefied gas, LPG, propane).The main components are gas burner, water tank, water-feeding pump, controlling system, furnace, pressure controller, pressure gauge, safety valve, sensor of water level. Comparing to traditonal steam boiler(coal, wood,pellet,biomass fired), gas steam boiler is more eco-friendly and efficent, without men on duty
The gas steam boiler is widely used in food cooking, clothes flat ironing, industrial cleaning, equipment cleaning, sauna room, sterilization, central heating etc.
Our advantages
1.High energy-saving efficiency
The gas steam generator adopts high-quality burner, designed with vertical 2 return-trip structure, the burning level is higher with over 90% thermal efficiency .
2. High steam capacity
The gas powered steam generator can output steam in 10 minutes and evaporates 300kg/h.
3. Easy to operate
The gas powered steam generator with steam capacity 300kg/h are smart fully automatic operated with accurate computerized circuit board.All functions are dispalyed on the control panel, the working process like steam temperature and pressure adjustable and controllable.
4. Highly safe
Safer than ever with 6 protection systems: pressure regulator system, Overpressure automatic protection, water lack protection, dry-fire protection, anti-explosion system.
5.With national patent certificate
The gas steam boiler is patented product with China patent certificate, guaranting the quality and cost performance, always environment-friendly with few noise and no smog.

Parameters
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
Evaporation
100 KG/H
Steam pressure
0.7 Mpa
Steam temperature
171 Degree celsius
Gas consumption
8.5m3/h(natural gas)
7 m3/h(liquefied gas)
7KG/h(diesel)
Voltage
380 V
Water tank volume
49L
Waste outlet diameter
DN40
Steam outlet diameter
DN20
Weight
350 KG
Dimension
800*760*2180 mm
Price
3459$
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
Detailed Images
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
Advanced conponents
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Germany burner

Saving fuel consumption 30% off
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Easy-operate panel
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Pressure controller and gauge
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Electric circuit board
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Pressure gauge
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean

Safety valve
Packing&Shipping
The steam generator product will be packed with wood material to make the delivery safe, freight way by air or by sea.
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
0.7Mpa Vertical Lpg Diesel Gas Steam Boiler Generator 100kg/H For Textile Laundry Clean
After Sales Service
After sales service
1.During the 1 year warranty time, the steam generator could be renewed if suffers bugs not by man-made intentional way. You can enjoy free maintenance service from us.
2. out of the 1 year warranty time, the steam generator maintenance service will be charged.
