Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
Specifications
Brand Name :
DSE
Model Number :
DSE7320 MKII AMF 7320-010-03
Certification :
CE, Rohs, ISO9001
Place of Origin :
UK
MOQ :
1 unit
Price :
USD 150.00-300.00 per unit
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1000 units per month
Packaging Details :
Original package or required by customer
Delivery Time :
3-5DAYS
Color :
Black
Weight :
0.9kgs
Material :
Hard rubber base
Feature :
Auto Mains (Utility) Failure
Power supply :
8 to 35 Vdc Continuous
Purpose :
Brushless Generator
Description

DSE7320 MKII, Auto Mains (Utility) Failure Control Module

DSE7320 MKII is a powerful, new generation Auto Mains (Utility) Failure genset control module with a highly sophisticated level of new features and functions, presented in the usual DSE user-friendly format. Suitable for a wide variety of single, diesel or gas Gen-set applications.

Featuring a new Dual Core main processor and extended memory, the module provides faster and more powerful processing power, returning faster operational responses on intensive applications and increased functionality, with data logging facility.

Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LED's, remote PC's and via SMS text alerts (with external communication device).

OVERALL SIZE
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")

PANEL CUTOUT SIZE
220 mm x 160 mm (8.7" x 6.3")

MAXIMUM PANEL THICKNESS
8.0 mm (0.3")

PRODUCT VARIANTS
7320-03 - 7320 MKII Auto Mains (Utility) Failure Control Module

Power Supply

8 to 35 Vdc Continuous

Cranking Dropouts:

Able to survive 0 V for 50mS, providing supply was at least, 10V before dropout and supply recovers to 5V without the Need for internal batteries.

Max Current

Operating 340 mA at 12 V, 160 mA at 24 V
Standby 160 mA at 12 V, 80 mA at 24 V 24V

Start Output:

15 A DC at supply voltage

Fuel Output:

15 A DC at supply voltage

Auxiliary Relay Outputs:

2 A DC at supply voltage

Charge Fail / Excitation Range

0 V to 35 V

Alternator Input Range:

15 V - 333 V AC (L-N)

Alternator Input Frequency:

3.5 Hz to 75 Hz

Mains Supply Input Range:

15 V - 333 V AC (L-N)

Mains Supply Input Frequency:

3.5 Hz to 75 Hz

Magnetic Pick-up Voltage Input Range:

+/- 0.5 V to 70 V

Magnetic Input Frequency:

10,000 Hz (max)

Operating Temperature Range:

-30 to +70°C

Panel Cutout:

220mm x 160mm ( 8.7” x 6.3”)

Material Controling Details as below

Robust Materials

products are made from the highest grade materials to ensure they provide premium levels of strength and rigidity.

Premium Components

We make sure every single component that goes into our products delivers outstanding levels of reliability.

Simplified Programming

Our intelligent Configuration Suite Software makes programming modules extremely simple.

Pictuers of goods with package show

Genset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMFGenset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMFGenset DSE Auto Generator Control Panel Failure Control Modules DSE7320 MKII AMF
