The TIANON G003 is a high-efficiency N-Type TOPCon bifacial double-glass solar module delivering 715-740W of power output with up to 23.04% module efficiency. Engineered with 156 half-cut 210*91mm N-Type TOPCon cells in a 2*78 configuration, the G003 leverages advanced multi-busbar technology to maximize current collection and minimize internal resistance losses for superior energy yield. With up to 25% bifacial gain, the G003 captures significant additional rear-side energy for enhanced total power generation in utility-scale, commercial and industrial PV installations.

The bifacial double-glass design features 2.0mm + 2.0mm high-transmission coated glass with a semi-tempered back sheet, delivering exceptional durability and long-term reliability. TIANON's advanced N-Type TOPCon cell technology provides superior resistance against LID and LETID degradation, ensuring stable performance throughout the module's 30-year operational life.

Built for demanding outdoor environments, the G003 features a reinforced double-glass structure supporting 2400Pa wind load and 5400Pa snow load. The IP68-rated junction box delivers superior waterproof protection and environmental durability. An anodized aluminum alloy frame provides structural integrity. All components are TUV-certified, ensuring international quality compliance. At 2465*1303*33mm and 38.5kg, the G003 is optimized for large-scale ground-mount, commercial rooftop and agricultural PV applications.

• N-Type TOPCon Technology - advanced N-Type cell architecture delivering 23.04% efficiency with reduced LID/LETID degradation for maximum lifetime energy yield.
• 715-740W Ultra-High Power - 156 half-cut 210*91mm cells with multi-busbar design maximizing power output for utility-scale PV project optimization.
• Up to 25% Bifacial Gain - double-glass bifacial design capturing significant rear-side irradiance for additional energy generation and improved LCOE.
• 2.0mm+2.0mm Dual Glass Structure - enhanced durability with high-transmission coated front glass and semi-tempered back glass for 30-year reliability.
• IP68 Junction Box Protection - highest-grade waterproof junction box ensuring superior environmental resistance for outdoor installations.
• 2400Pa Wind / 5400Pa Snow Load - reinforced double-glass construction meeting demanding mechanical load requirements for diverse installation environments.
• Premium Manufacturing Quality - anodized aluminum alloy frame, TUV-certified components and strict quality control for consistent international-grade products.
• Factory Direct OEM/ODM Supply - professional manufacturing capability supporting bulk orders and customized cooperation for global partners.

• Utility Solar Farms - large-scale ground-mount PV plants maximizing energy density with 740W modules
• Commercial PV Projects - commercial and industrial solar installations benefiting from bifacial gain
• Industrial Solar Systems - factory and manufacturing facility solar power with high mechanical load ratings
• Rooftop Solar Applications - commercial and industrial rooftops with bifacial energy harvesting potential
• Agricultural Solar - agrivoltaic applications combining solar generation with agricultural land use

1. What is the power output? - 715-740W with up to 23.04% module efficiency using N-Type TOPCon technology.
2. What cell technology is used? - 210*91mm N-Type TOPCon cells with 156 half-cell (2*78) configuration.
3. What is the bifacial gain? - Up to 25% additional energy from rear-side irradiance with double-glass design.
4. What are the mechanical load ratings? - 2400Pa wind load and 5400Pa snow load with reinforced double-glass construction.
5. What are the dimensions and weight? - 2465*1303*33mm, 38.5kg per module with anodized aluminum alloy frame.

Shaanxi Tianon New Energy Technology Co., Ltd. is a professional manufacturer of integrated energy storage and solar conversion systems. With dual manufacturing hubs in Xi'an and Anhui and over 10 years of new energy export experience, we deliver premium-quality products backed by rigorous quality inspection and international certification. We serve distributors, EPC contractors, and project developers in 50+ countries across Europe, North America, and Southeast Asia.
