5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
5300KN 168MPa 130rpm Plastic Injection Molding Machine
Specifications
Brand Name :
HAIJIA
Model Number :
HJF 530
Certification :
CE ISO9001
Place of Origin :
China (Mainland)
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000set/sets per year
Delivery Time :
20-30days
Packaging Details :
Standard Export Package for Injection Machine
Injection Rate :
449
Injection Pressure :
168
Screw Speed :
0-130
Max.Pump Pressure :
17.5
Pump Motor Power :
45
Heater Power :
31.4
Description

High performance and high accurate injection molding machine for plastic plant

1.Hydraulic closed loop and motor speed closed loop is realized by control system with the features of high repetition, high linearity, high linearity, high efficiency, high precision, fast response, low rejection rate,low noise, low vibration and long service life, High-rigidity template design with T shot andordinary threaded hole facilitates the mold installtion. Oil filter equipment of high performance and high precision can keep the grease within NAS8. Color control system is adopted.

2. Injection Unit Features

2.1 Injection unit adopts duble-cylinder design, more higher injection pressure, more simpler structure and lower malfunction rate.

2.2 Enlarged-cylinder, adopting two -cylinder design,effectively prevent the adhesive-material leaking phenomenon because of the machine vibration or other reasons when the nozzle is under high-speed operation.

2.3 Adopting graphite bush, improving the wear-resistance, reducing the frequency of using lubrication oil effectively improve the cleanness of the injection part.

2.4 Injection cylinder adopts low-frictional seals, improving the response rate and improve the stability under the complicated processes of injection.

2.5 Bridge-style design, for different L/D plastic parts.

5300KN 168MPa 130rpm Plastic Injection Molding Machine

SPECIFICATION HJF240
Screw Type A B C
Screw Diameter Mm 75 80 85
Screw L/D Ration L/D 22.7 21 20
Shot Size(Theoretical) cm3 1727 1965 2218
Injection Weight(PS) g 1560 1788 2018
Injection Rate g/s 386 442 499
Injection Pressure MPa 191 168 148
Screw Speed rpm 130
Clamping Force KN 5300
Opening stroke Mm 820
Space Between Tie Bars mm 820*820
Max.Mold Height mm 810
Min.Mold Height mm 330
Ejector Stroke mm 240
Ejector Tonnage KN 150
Max.Pump Pressure MPa 17.5
Pump Motor Power KW 45
Heater power KW 31.4
Machine Dimension(L*W*H) M 8.4*1.92*2.76
Machine weight T 20
Oil Tank Capacity L 900
