5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
Specifications
Brand Name :
LIANHE
Model Number :
LH-VME 5
Certification :
CE , ISO , SGS , TUV
Place of Origin :
China
MOQ :
1
Price :
Contact Us
Payment Terms :
T/T, L/C, D/A, D/P, Cash
Supply Ability :
25 Sets per Month
Delivery Time :
25 working days
Packaging Details :
Normally packaged in wooden case or wrapping film, also can be customized
Product name :
Lab Cream Emulsifiers Small Lab Cream Lotion Mixer
Lab Capacity :
5-50L
Heating method :
electric
Usage :
cream mixing machine
Application scope :
Chemical Cosmetic Food Pharmacy
Power(W) :
Base on the size
Description

5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer

Product Description:

Vacuum emulsifying machines are widely used in various industries because they provide a cost-effective and low-material-loss method of handling materials that need mixing and emulsification. The industrial mixing of liquids, solids, and powders may all be done with the vacuum emulsifier. A vacuum emulsification machine is a full vacuum mixer system used in the cosmetics, pharmaceuticals, food, and chemicals industries to produce viscous cream, lotion, ointment, and suspensions.

Product Composition:

The vacuum emulsifying mixer is mainly composed of water pot, oil pot, emulsifying pot, vacuum system, lifting system (optional), electric control system (PLC is optional), operation platform, etc.

Product Structure:

The emulsifying machine is primarily comprised of an emulsification tank (with a liftable tank lid or flip tank), an oil phase tank, a water phase tank, a vacuum system, a heating and temperature control system, and an electrical control system. The vacuum emulsifier has more adaptability and diversity in material handling due to the replaceable operating unit, adjustable speed and frequency conversion, and temperature control system.

Product parameters:

Capacity (L) Homogenizer Agitator Vacuum pump Heating system
power (kw) speed (rpm) power (kw) speed (rpm) power (kw) Limit vacuum Electric heating (kw) Steam heating (Mpa)
5 0.55 0-3600 0.4 0-65 0.37 -0.1 6 0.2
10 1.1 0-3600 0.55 0-65 0.37 -0.1 6 0.2
20 1.5 0-3600 0.55 0-65 0.37 -0.1 9 0.2
50 3 0-3600 0.75 0-65 0.75 -0.1 12 0.2
100 4 0-3600 1.5 0-65 1.5 -0.1 24 0.2
200 5.5 0-3600 1.5 0-65 2.2 -0.1 28 0.2
300 7.5 0-3600 3 0-65 2.2 -0.1 32 0.2
500 11 0-3600 4 0-65 4 -0.1 50 0.2
1000 15 0-3600 5.5 0-65 4 -0.1 54 0.2
2000 18.5 0-3600 7.5 0-65 5.5 -0.1 recommend steam heating 0.2
5000 22.5 0-3600 15 0-65 7.5 -0.1 0.2
The parameters for reference only, all the machines can be customized accordingly.

Product Application:
The vacuum emulsifying mixer are mainly used to make high viscosity emulsions, especially creams, ointments and lotions. The functions of heating, cooling, dissolving, emulsification and vacuum defoaming can be completed at one time with an emulsifier; the raw materials can be fully pulverized, mixed, emulsified and homogenized to increase the gloss and stability of the product.
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer

Now, look at a few industries that use vacuum emulsifying mixer:

1. Cosmetic Industry

2. Pharmaceutical Industry

3. Food Industry

4. Chemical Industry

Product Details:
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer

FAQ:
Q1:Do you supply OEM/ODM service?
Yes, according to customer product requirements to design product shape and size .3D drawing provided.
Q2:What about the production time?
15-30days, except in stock.
Q3:How to install and operate machine?
I.All machines with English Language Manual;
II.Each working unit installation and operation video;
III.3D drawing for product shape and size;
IV.24h e-service online and on site operation live video for teaching;
V.Each machine working unit drawing provided.

Our Servers:

We provide Turn-key project service to customer.

1. Factory Layout design;

2. Factory Decoration based on GMP standard;

3. Formula of products;

4. Raw material etc;

5. Machine design, whole production line from A to Z;

6. Shipping service, FOB, CFR, CIF etc;

7. Installation service. Training service, Mainte

Rich Experience:
5L High Speed Lab Cream Vacuum Emulsifier Homogenizer Lotion Vacuum Mixer
