Specifications
Model Number :
RM type
Place of Origin :
Zhejiang, China
Brand Name :
careful
Certification :
ROHS
MOQ :
1000 pieces
Price :
$0.02-1.20/pieces
Type :
soft
Supplier Type :
factory
Application :
electronic and electrical equipment
Brand :
careful
Package Type :
carton
Operating Temperature :
<300℃
Tolerance :
20%
Package / Case :
as the customer required
Material :
MnZn Power Ferrite
MOQ :
10pcs
Packing :
Carton
Sample :
Avaliable
Lead time :
7-20 Days
Packaging Details :
Standard exporting carton or as customer's request
Delivery Time :
7-20 Days
Description
Products Description
RM8/10/14 type PC40/PC44/PC90 MnZn Material Ferrite for Transformer
RM8/10/14 type PC40/PC44/PC90 MnZn Material Ferrite for Transformer
RM8/10/14 type PC40/PC44/PC90 MnZn Material Ferrite for Transformer
RM8/10/14 type PC40/PC44/PC90 MnZn Material Ferrite for Transformer
RM8/10/14 type PC40/PC44/PC90 MnZn Material Ferrite for Transformer
Place of Origin
China,Zhejiang
Brand Name
Careful
Model Number
RM Type
Type
Soft
Composite
Ferrite Magnet
Shape
Pot / Cup Shape
Application
Industrial Magnet
Tolerance
±10%
Frequency
1khz-1mhz
Certification
ISO9001-2015, SGS-ROHS,REACH
Material
MnZn(Manganese,Zinc)
Impedance
As customer's requirement
MOQ
No MOQ for the trial order
Curie TC
140°C-265°C
Samples/delivery
5-10pcs free samples for freight collect. /5-7days

Specifications Dimensions:mm
A B C D
RID 2×2.3×3.5 2±0.3 2.3±0.3 3.5±0.3 1±0.3
RID 3.5×2×1.3 3.5±0.3 2±0.3 1.3±0.3 0.8±0.3
RID 3.5×2×2 3.5±0.3 2±0.3 2±0.3 0.8±0.3
RID 3.5×2×2 3.5±0.3 2±0.3 2±0.3 1.2±0.3
RID 3.5×2×2.4-0.8 3.5±0.3 2±0.3 2.4±0.3 0.8±0.3
RID 4×7×3-2.2 4±0.3 7±0.3 3±0.3 2.2±0.3
RID 4.1×6.9×6.6 4.1±0.3 6.9±0.4 6.6±0.4 1.8±0.3
RID 4.6×8.8×5-2.3 4.6±0.3 8.8±0.3 5±0.3 2.3±0.3
RID 5×3×3 5±0.4 3±0.3 3±0.3 1.2±0.3
RID 5.2×3×2-1 5.2±0.3 3±0.3 2±0.3 1±0.3
RID 5.2×3×2-1.2 5.2±0.3 3±0.3 2±0.3 1.2±0.3
RID 5.59×3.05×3.1-1.27 5.59±0.3 3.05±0.3 3.1±0.3 1.27±0.3
RID 5.6×3.05×3-1.27 5.6±0.3 3.05±0.3 3±0.3 1.27±0.3
RID 6.5×3×3-1 6.5±0.3 3±0.3 3±0.3 1±0.3
RID 6.5×3×3.2 6.5±0.4 3±0.3 3.2±0.3 1±0.3
RID 6.5×3×3.2-1.2 6.5±0.3 3±0.3 3.2±0.3 1.2±0.3
RID 6.5×3×3.5 6.5±0.4 3±0.3 3.5±0.3 1.5±0.3
RID 6.5×3×3.6-1.1 6.5±0.3 3±0.3 3.6±0.3 1.1±0.3
RID 6.9×4.1×6.6-1.8 6.9±0.3 4.1±0.3 6.6±0.3 1.8±0.3
RID 7×4×3-1.8 7±0.3 4±0.3 3±0.3 1.8±0.3
RID 7×4×3 7±0.4 4±0.3 3±0.3 2±0.3
RID 7×4×3-2.2 7±0.3 4±0.3 3±0.3 2.2±0.3
RID 7×4×8-1.8 7±0.3 4±0.3 8±0.3 1.8±0.3
RHH 7×6.8×5.6 7±0.4 6.8±0.4 5.6±0.4 1.5±0.4
RID 7.5×2.3×7.5-0.8 7.5±0.3 2.3±0.3 7.5±0.3 0.8±0.3
RID 7.8×5×6.7×2.8-2.2(方孔) 7.8±0.3 5±0.3 6.7±0.3 2.2±0.3
RID 8.4×4.4×8-2 8.4±0.3 4.4±0.3 8±0.3 2±0.3
RID 8.4×4.4×8 8.4±0.4 4.4±0.3 8±0.4 2.1±0.3
RID 8.8×4.6×5-2.3 8.8±0.3 4.6±0.3 5±0.3 2.3±0.3
RID 12×6.5×4 12±0.5 6.5±0.4 4±0.3 3.8±0.3
RID 12×6.5×4-4 12±0.4 6.5±0.3 4±0.3 4±0.3
RID 12×6.5×6-3.8 12±0.4 6.5±0.3 6±0.3 3.8±0.3
RID 12×6.5×7-4 12±0.4 6.5±0.3 7±0.3 4±0.3
RID 12×6.5×8-3.8 12±0.4 6.5±0.3 8±0.3 3.8±0.3
RID 12×6.5×10 12±0.5 6.5±0.4 10±0.5 3.8±0.3
RID 12×6.5×10-4 12±0.4 6.5±0.3 10±0.4 4±0.3
RID 12×6.5×14-3.8 12±0.4 6.5±0.3 14±0.4 3.8±0.3
RID 12×6.5×14-4 12±0.4 6.5±0.3 14±0.4 4±0.3
RID 13×7.5×2.5 13±0.5 7.5±0.4 2.5±0.7 3.8±0.3
RID 13×7×14.35-3.7 13±0.4 7±0.3 14.35±0.4 3.7±0.3
RID 13×7.5×14.35-3.7 13±0.4 7.5±0.3 14.35±0.4 3.7±0.3
RID 13×7.5×14.35 13±0.5 7.5±0.4 14.35±0.5 3.8±0.3
RID 13×7.5×25-3.8 13±0.4 7.5±0.3 25±0.5 3.8±0.3
RID 13×7.5×25-4 13±0.4 7.5±0.3 25±0.5 4±0.3
RID 13×7.5×27-3.8 13±0.4 7.5±0.3 27±0.5 3.8±0.3
RID 13.4×7.5×10-4.2 13.4±0.4 7.5±0.3 10±0.4 4.2±0.3
RID 23.5×10.5×25-6.4 23.5±0.5 10.5±0.4 25±0.5 6.4±0.3
RID 32×16×22-8.3 32±0.6 16±0.4 22±0.5 8.3±0.4
RID 32×16×32 32±1.0 16±0.5 32±1.0 8.3±0.4

Company Profile
RM8/10/14 type PC40/PC44/PC90 MnZn Material Ferrite for Transformer
Huzhou Careful Magnetism Co., Ltd. is a technically leading corporation, integrating production, management, research, development and service. Our company was established in 2001, Huzhou Careful Magnetism Co., Ltd - a key enterprise in Huzhou City. Our company was assessed as "High and New Technology Enterprise in Zhejiang Province". We have more than 20 years of experience in the field, as our boom development, now we own 3 factoies to service more and more clinets.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
1. Who are we?
We are based in Zhejiang, China, start from 2001, sell to Domestic Market(60.00%), Eastern Europe(10.00%), South Asia(5.00%), Eastern Asia(5.00%), North America(5.00%), Northern Europe(4.00%), South America(3.00%), Southern Europe(3.00%), Western Europe(2.00%), Oceania(1.00%), Central America(1.00%), Southeast Asia(1.00%). There are total about 1000+ people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment.

3.What can you buy from us?
Soft Ferrite Core, Amorphous core, Inductors, NiZn ferrite.

4. Why should you buy from us not from other suppliers?
We are the biggest manufacture of ferrite core in China for more than 30 years, also with production line of Amorphous core, SMD core, inductors for years. We are already the supplier of Microsoft, GREE, Midea, SAMSUNG, ASUS, Panasonic, etc.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, Express Delivery; Accepted Payment Currency: USD, CNY; Accepted Payment Type: T/T, L/C, PayPal, Western Union, Escrow; Language Spoken: English, Chinese.
