Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Specifications
Brand Name :
Sihovision
Model Number :
SC215
Certification :
CE, FCC, RoHS
Place of Origin :
China(Mainland)
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T,Western Union,MoneyGram,Paypal,D/P,D/A,L/C
Supply Ability :
50000pcs/month
Delivery Time :
7 days
Packaging Details :
carton
Product name :
Magnetic Adsorption Panel PC
Cpu :
J4125
Memory :
8GB
Storage :
128GB
Resolution :
1920*1080
Brightness :
1000cd/m2
Material :
Aluminum Alloy
View Angle :
89°/89°/89°/89° (R/L/U/D)
Touch Type :
10 Points Capacitive Touch
Type :
Panel PC
IP Grade :
Front panel IP65 waterproof
Working voltage :
DC 12V
Warranty :
12months
Feature :
Optical Bonding
Description

Features


1. Intel Celeron J4125 Quad Core CPU 2.0GHz;
2. 8GB RAM memory, 128GB Industrial SSD
3. Supports Windows 10 & Linux (32Bit, 64Bit)
4. Anti-glare surface treatment (chemical etching)
5. 10-Point Multi Touch Capacitive Touch Panel
6. 3mm cover glass with 6H surface hardness
7. Optically bonded Touch Panel to LCD Panel
8. Patented IP65 front with silicon seal
9. Shell structure can be customized



Specification

PC System
CPU J4125
Graphic GPU Intel
Memory 1xSO-DIMM DDR4 Memory,Max.8GB
Storage (switchable) 128GB SSD
Driver Support Win10; Linux; 32Bit/64Bit
Pre-installed OS Win10
Display Characteristics
Diagonal 21.5"
Panel LCD, Anti-glare coating
Native resolution 1920(H) ×1080(V)
Aspect ratio 16:9
Brightness 1000 cd/m2
LED Life Time 30,000 Hour
Contrast Ratio (Center of screen) 1000:1
Response Time 10ms
Viewing zone horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Support Color 16.7M colors
Touch
Touch technology projective capacitive
Touch points 10
Touch accuracy ±2mm
Surface Treatment Anti-glare (chemical etching)
Touch interface USB
Supported operating systems win7 ,win10, Linux ,android
Through-Glass 3mm
Touch scheme EETI
Mechanical
Fanless design yes
MTBF 50,000 Hour
Cable management system yes
Operation temperature -20°C - 70°C
AngeStorage temperature range - 30°C - 80°C
Power Management
Power supply unit External
Power supply DC 12V
Rated output current 6A
Installation Method
VESA 100mm*100mm
External Connectors
DC-In ×1
HDMI ×1
USB ×4
Audio(Line-out,Mic-in) ×2
VGA ×1
RJ45 ×1
Com ×2
Weight
Box dimensions W x H x D 654 x 486 x 185mm
Weight (without box) 9.6kg
Weight (with box) 13kg
Product country origin China


Certifications
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD

OEM & ODM

Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD

About Shinho Electronic
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD
Application
Optical Bonding Anti Glare Fanless Panel PC J4125 8GB 128G SSD


Application
Smart City
Intelligent Education
Public Transportation
Commercial Terminals
Industrial automation area
Product Stamping and Packaging
