6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
Specifications
Brand Name :
MESTECHS
Model Number :
MDS5006
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Supply Ability :
200sets/week
Packaging Details :
Command package
Price :
Negotiable
Delivery Time :
45 work days
Transmission distance :
up to 6.5km
Port :
6 ports
High bandwidth :
up to 100Mbps
Size :
1U
application :
industrial Outdoor
Description

MDS5006 6 ports ADSL VDSL2 Communication concentrator Long range High Uptream

MDS5008 is a DSL communication concentrator equipment launched by our company based on long-distance copper wire transmission (video big data application scenario). It adopts our company's unique HUDSL (high uptream DSL) technology and makes full use of ADSL high downlink bandwidth channel for HD video monitoring. Its main features are as follows:

1) Special ADSL reverse bandwidth technology makes full use of high bandwidth channel to transmit big data and low bandwidth channel to transmit control signals

2) The maximum bandwidth of single channel is 24m, and the longest distance is 6.5km

3) Use together with mds1000 of hudsl terminal equipment of our company

4) It supports multi-channel convergence, star networking, dual network interface connection, and cascade (expansion port)

5) Each DSL adopts independent channel and bandwidth, Ethernet convergence and uplink

6) Built in hardware watchdog to improve transmission reliability

7) Industrial operating temperature range - 40 ℃ ~ 70 ℃

Typical applications


Railway, coal, port and other high-definition video monitoring

Shape and dimension

6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
Internal block diagram

6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream
Electrical characteristics

Electrical characteristics
DSL Interface (6 ports) Modulation Mode OFDM
Modulation Band

ADSL: 4K~2MHZ

VDSL2: 2M~30MHZ
Transmission Speed

ADSL: 24Mbps

VDSL2: 100Mbps
Standard ITU-G992.1/G992.3/G992.5/G993.2
Agreement ADSL/ADSL2/ADSL2+/VDSL2(17a)
ETH Interface(2 ports) Standard IEEE 802.3/ IEEE 802.3u
Communication Mode 10M/100M self-adaption
Performance Parameter Operating Temperature - 40 ℃ ~ + 70 ℃
Operation Humidity 20%-85%
SIze 19 inch/1U rack
Power Supply 100V~240V AC
Maximum power consumption <30W


Application block diagram

6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream

6.5km 1U 6 Ports DSL Router , ADSL VDSL2 Router Long Range High Uptream


Order Information

Product Description Order Code
6 ports ADSL VDSL2 Communication concentrator ​MDS5006
