Description

SFTC-HCB-VRK (SM-04-VRK) Elevator Hall Call Display Board / Outer Call Panel For STEP Elevator Parts Replacement Parts


Floor Display
Highlighted red segment codes / dot matrix display of the current elevator floor (1, 2, 3...)
Clearly displays elevator up (↑) / down (↓) direction of travel
External Call Command Reception
Receives up/down button signals from outside the hall and sends a call request to the elevator main control system
Button indicator light on: Indicates the call has been registered; light off: Elevator has arrived and responded
Status Information Display
Full load, fire alarm, overload, park, etc.
Fault Code Display (for easy maintenance)


Brand SULAB
Description Elevator parts
Model SFTC-HCB-VRK
MOQ 1PC
Transportion TNT, UPS, DHL, Fedex, Air, Sea
Applicable Elevator
Packages Carton, Wooden case, Pallet etc
Delivery Time Normally 2-3 working days after payment
Warranty One year
Payment Method Company Bank, Western union, Paypal etc


Communication and Control

CAN bus communication for stable signal transmission with the Xinshida motherboard (e.g., AS380)

Supports floor address DIP switch settings (FLOW/SET jumper pins)

Built-in terminating resistor (CAN DIP switch) to ensure stable long-distance communication

Applicable Scenarios
Xinshida system passenger elevators and freight elevators

Alternative Models: SM-04-VRF, SM.04VR/K, SM-04-VRE, etc.

Elevator Display - FAQ

Q1: What types of displays are used in elevator systems?
Elevator systems use LED indicators, LCD screens, including TFT LCD displays, and other display technologies to show floor numbers, travel direction, and operating status.

Q2: Are elevator displays with the same screen size interchangeable?
Not necessarily. Displays with the same dimensions may differ in supply voltage, communication protocols, connector configurations, and control requirements. Compatibility must be verified before replacement.

Q3: What causes an elevator floor display to show incorrect information?
Possible causes include communication errors, controller configuration problems, wiring faults, or display module failure. The actual cause should be identified before replacement.

Q4: Can an elevator display be upgraded without replacing the control system?
In some systems, the display can be upgraded separately if the replacement supports the existing controller, communication protocol, and electrical requirements.

Q5: What information is required to order a replacement elevator display?
Please provide the original part number, display type, screen dimensions, supply voltage, communication interface, connector details, controller model, and clear photos for accurate matching.
