Specifications
Brand Name :
OEM
Model Number :
Limit Switch CR137-BZ-T2
MOQ :
1
Payment Terms :
D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
3-5 Working Days
Type :
CR137-BZ-T2
Product name :
Limit Switch CR137-BZ-T2 | Roller Lever, IP54, 10 A 250 V
Transportation :
Clients' Requestment,DHL TNT FEDEX UPS,Sea Delivery
Application :
Elevator Parts
Business type :
manufacturer
Keywords :
Elevator Parts ,Elevator Safety ,Limit switch CR137-BZ-T2
Packing :
Packed in carton
Description

Limit Switch CR137-BZ-T2 | Roller Lever, IP54, 10 A 250 V | Industrial Position & Safety Switch


CR137-BZ-T2 is a heavy-duty limit switch built for reliable position feedback and safety circuits on conveyors, hoists, packaging machines and automated doors. Its snap-action, positive-break NC contact guarantees machine stop even on contact weld, while the IP54 glass-fibre reinforced housing shrugs off dust, oil and 80 °C peaks without de-rating.
Key advantages
  • Positive-break NC contact – failsafe per IEC 60947-5-1
  • Fixed roller lever – repeatable 1.5 mm pre-travel, no field adjustment
  • IP54 protection – indoor or outdoor panel mount
  • 30-million-cycle mechanism – cut maintenance downtime
  • Two M20 cable entries – fast wiring, double cable glands possible

Specification Value
Type CR137-BZ-T2
Contact arrangement 1 NC positive-break + 1 NO
Thermal current 10 A
Rated insulation voltage 250 V
Utilization category AC-15: 3 A / 250 V, DC-13: 0.3 A / 250 V
Protection degree IP54 (IEC 60529)
Housing / lever Glass-fibre reinforced PBT / stainless-steel roller
Cable entries 2 × M20 × 1.5 (cable Ø 6 … 12 mm)
Operating / release force ≤ 15 N / ≥ 4 N
Pre-travel / over-travel 1.5 mm / ≥ 3 mm
Mechanical life ≥ 30 million operations
Ambient temperature –30 °C … +80 °C
Mounting 2 × captive M5 × 30 mm screws
Weight ≈ 0.15 kg
Typical applications
Elevator limit & slowdown, overhead-door end-stop, conveyor over-travel guard, packaging-machine position feedback.
