  • SIGMA DCD-23 S2.1 Door Operator Board - Original Elevator Spare Part AEG09C220B

    The SIGMA DCD-23 S2.1 Elevator Door Operator Board (Part No. AEG09C220B / KAA24350AAB) is a critical control component designed for precise and reliable operation of elevator door systems. This high-performance PCB serves as the central processing unit for door motor control, ensuring smooth, safe, and efficient door opening and closing sequences in LG-Sigma elevator installations.
    Engineered with sophisticated microprocessor technology, the DCD-23 board integrates seamlessly with elevator control systems to manage door speed profiles, position feedback, torque control, and safety monitoring. Its robust design and proven reliability make it an essential replacement part for maintenance and modernization projects.

    Parameter Specification
    Model Number DCD-23 S2.1
    Part Numbers AEG09C220B, KAA24350AAB
    Board Type Door Operator Control PCB
    Control Method VVVF Inverter Control with Position Feedback
    Input Voltage 24V DC ±10% (Control Circuit) / 110-220V AC (Power Circuit)
    Output Power 400W Continuous, 800W Peak (3 sec)
    Control Outputs 3-Phase AC 0-230V, 0-120Hz
    Signal Inputs Door zone sensor, encoder feedback, safety edge, light curtain
    Communication Interface RS485 for elevator controller integration
    Operating Temperature -10°C to +60°C
    Protection Rating IP20 (control board), IP54 when installed in enclosure
    Dimensions 200mm × 150mm × 40mm (L×W×H)
    Weight 0.68 kg
    Certifications CE, UL 508, ISO9001

    Applications & Compatibility

    Suitable for:
    • LG-Sigma DSS, DI/DS series elevators
    • Door operators: SAV1, SBD1, SDC, SDC-V models
    • Landing door systems with AC induction or PM motors
    • New installations and modernization projects
    Compatible Elevator Models:
    • SIGMA DSS-1, DSS-2 series
    • LG DI, DS commercial elevators
    • Custom applications with SIGMA door systems

    Installation & Configuration

    1. Mounting: Install in vertical position with adequate ventilation (minimum 50mm clearance)
    2. Wiring: Follow wiring diagram supplied with board; ensure proper grounding
    3. Parameter Setup: Use DOA-100 server or SVC Tool Kit (software version 2.1 or higher)
    4. Motor Auto-Tuning: Required on first installation for optimal performance
    5. Safety Testing: Perform full door operation test per EN81 standards before commissioning
    Note: Professional installation by certified elevator technician is mandatory.
