Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length
Specifications
Brand Name :
AP&T
Model Number :
AP-AB1602
Certification :
Ex-proof , CE ISO9001
Place of Origin :
SHANGHAI CHINA
MOQ :
1
Price :
USD 300-550 pcs
Payment Terms :
T/T, L/C
Supply Ability :
600pcs per month
Packaging Details :
carton
Delivery Time :
3-7 working days after payment
Model :
AP-AB1602
Explosion-proof mark :
Ex s ⅡB T4 Gb
Explosion-proof certificate No. :
GYB16.1549X
Working voltage :
Power frequencyAC4000V
Bar body length :
110—3000mm
Ion balance :
≤|±100V|
Discharge speed :
≤2.5S（Working distance 100mm）
Electrode binding capacity :
＜3.5pF
HV cable length :
2.5m（customize available, maximum 8m）
Key words :
ion bar, antistatic bar
Description

Air Source AC Voltage Antistatic Bar Customizable

Specification

Model

AP-AB1601

AP-AB1602

Explosion-proof mark

Ex s ⅡB T4 Gb

Ex s ⅡB T4 Gb

Explosion-proof certificate No.

GYB16.1549X

GYB16.1549X

Working voltage

Power frequencyAC4000V

Power frequency AC4000V

Power

20W

20W

Electrode HV

≤4000V

≤4000V

Electrode binding capacity

＜3.5pF

＜3.5pF

Discharge distance

30－150mm

100－600mm

Ion balance

≤|±100V|

≤|±100V|

Discharge speed

≤2.5S(Working distance 100mm)

≤2.5S(Working distance 300mm)

Working temperature

0°C - 50°C

0°C - 50°C

Working humidity

＜70%

＜70%

Bar body length

110—3000mm

110—3000mm

HV cable length

2.5m(customize available, maximum 8m)

2.5m(customize available, maximum 8m)

Power supply

AP-AY1603/2603

AP-AY1603/2603

Industry application


It can be widely used in printing, plastic, textile and other industries with flammable conditions. Especially suitable for the industries that may have combustible solvent or combustible gas.


Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length

Air Source AC Voltage Customizable ESD Ionizer Anti Static Bar 110 - 3000mm Bar Body Length

Electrode

Power supply

Voltage
(V)

Frequency
(Hz)

Needle binding content
(pF/group)

Primary voltage
(V)

Secondary voltage
(V)

Frequency
(Hz)

Capacity
(VA)

Insulation grade

4000

50
60

3.5

100
110
220

4000

50
60

25

E


Special conditions for safe use of the product

The explosion-proof certificate number suffix "X" shows that the product has special conditions for safe use, the specific contents are as follows:

  • The electrode of ion bar should be kept clean. Dry cleaning of electrode support is strictly prohibited.

  • The product can not be used in places where conductive objects are likely to be attached to the electrodes (Can not be used if carbon, metal foil and other conductive objects may be attached to electrodes of ion bar).

  • The distance between the electrode of ion bar and the object should be more than 20mm.

  • The distance between the electrode of ion bar and the mechanical frame should be more than 10mm.

  • The power supply device does not have the explosion-proof structure and must be set in the non dangerous place.

  • The maximum length of the high voltage cable is 8m.

  • It is strictly prohibited to use when cover is open.

  • Friction on products outer surface is strictly prohibited to prevent static ignition risk.

Packaging & shipping

Payment Term

T/T, L/C, West Union, Paypal

Delivery Time

7 to 10 days after confirm the order

Warranty

1 years after delivery

Package

Carton
