12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
Specifications
Brand Name :
Xingtongli
Model Number :
GKD12-3000CVC
Certification :
CE ISO9001
Place of Origin :
China
MOQ :
1pcs
Price :
1630-2160$/unit
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
200 Set/Sets per Month
Delivery Time :
5-30 working days
Packaging Details :
strong plywood standard exporting package
Description

This 12V 3000A electroplating rectifier is built for demanding industrial plating applications, converting 380V three-phase AC input into stable and precise DC output. It features advanced control systems for accurate voltage and current regulation, efficient heat dissipation, and a rugged design for continuous, reliable operation. Suitable for high-current electroplating processes such as copper, nickel, and chrome plating.


Technical Parameters

  • Input Power: Three-phase 380V AC ±15%, 50/60Hz

  • Output Capability:

    • Voltage: DC 0-12V continuously adjustable

    • Current: DC 0-3000A continuously adjustable

    • Power: Max. 36kW (12V × 3000A)

  • Regulation Accuracy: Voltage ±1%, Current ±1%

  • Efficiency: ≥89% (high-frequency IGBT soft-switching technology)

  • Cooling System: Intelligent temperature-controlled fan (low noise, load-adaptive speed adjustment)

  • Communication Interface: DP interface (RS485, Modbus protocol support)

  • Protection Features: Over-voltage, over-current, short-circuit, overheating, input surge protection

  • Control Modes: Local keypad control / remote communication control (auto CC/CV switching)

  • Display Interface: LCD screen (real-time voltage, current, fault codes)

  • Operating Temperature: -10℃ to +45℃

  • Protection Rating: IP20 (basic dust protection)


Typical Applications

  • Small-Batch Electroplating: Gold/silver plating for jewelry, nickel plating for hardware accessories.

  • Electrolytic Repair: Mold surface restoration, metal part derusting.

  • Laboratory Research: Electrochemical experiments, power supply for small electrolytic cells.

  • Vocational Training: Electroplating process teaching equipment for technical institutes.

  • 12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
  • 12V 3000A Electroplating Rectifier 3-phase 380V Input High-frequency Adjustable DC Power Supply
