5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS
Specifications
Model Number :
Customized
Brand Name :
Edgarcn
Place of Origin :
Guangdong, China
Certification :
RoHS, UL, ISO9001,IATF16949
MOQ :
500
Price :
$5-15
Part number :
Cable 5C908
Wire length :
30cm
Wire AWG :
UL1007-22AWG
Wire color :
Black & Red
Fuse count :
2
Wire material :
PVC
Wire temperature :
105℃
Wire voltage :
300V
Connector type :
MOLEX
Process type :
Over molding
Pin count :
20
Primary VCC :
White/Red
Primary Ground :
Black
Host RXD :
Green
Host TXD :
Blue
Description

Edgarcn 5C908 fuse automotive wire harness

Edgarcn 5C908 fuse automotive Cable assembly

Edgarcn 5C908 fuse automotive wiring harness

Specification
Part number Cable 5C908
Wire length 30cm
Wire AWG UL1007-22AWG
Color Black & Red
Other with 2 fuses
Application Auto

Molex micro-fit 20 Pin out

Pin Number

Signal description

Color

Pin Number

Signal description

Color

1

Ground

Black

11

Output 2

White/Yellow

2

Output 0

Green

12

Input 2

Brown

3

Input 1

Yellow

13

Host RXD

Green

4

Host TxD

Blue

14

Primary VCC input

White/Red

5

ADC1 Input

Orange

15

Primary Ground

Black

6

Reserved

Red

16

1 Bit Bus GND

Black

7

Reserved

White

17

1 Bit Bus Data

White/Blue

8

Ignition

Violet

18

Aux Port – TX data

White/Orange

9

V00

Orange

19

Aux Port – GND

Black

10

Output 1 /Boot

Blue

20

Aux Port – Rx data

White/Yellow

Edgar Service 4

5C908 Fuse Holder Automotive Wire Harness with PVC Wire 105℃ 300V and UL1007-22AWG Wire for Truck GPS

Company information

Packaging Details could be customized by client specified.
Normally, the lead time below for reference, the detail according to conversation:

Quantity (PCS) 1 - 1000 1001 - 5000 >5000 Mold/ tooling
Est. Time(Days) 20 25 To be negotiated 30 days more

International expressed by DHL, UPS, FedEx, TNT, ARAMEX and EMS etc..

Customers choice for shipping by air, sea or others.

Payment for samples/mass products shall be closing before delivery, amount above 5000 USD according to conversation in somewhere.

Molex/Tyco/JST standard connector wire harness, USB data cable, Modular RJ 45 Cat cable,

Power DC cable, D-sub data cable, Mini Din, RCA cable and IDC flat ribbon cable etc.

1. Q: Can you help to design?

A: Yes, we are an ODM / OEM company, beyond we have been specializing in wire harness & Cable assembly since 1999.

2. Q: When will you start to help design?

A: We sketch simple solution for initial discussion, after quotation and order placed then start to drawing and double confirm with client for the design.

3. Q: What if quality issues occur when customer discover?

A: Our quality and engineer team will positively respond for the quality issues with 72 hours, as we are intend to make long-stand strategy with customer and the value is to provide better service.

4. Q: Do you have any standard products to cut down customers lead time for prototype and tooling cost?

A: Yes, we have developed over 1000 sets of molds and some of them can be used for customer directly. Besides, we specialize in wire harness over 20 years with more than 5000 products
