Concrete Cube Testing Machine , Digital Display Concrete Lab Equipment
Concrete Cube Testing Machine , Digital Display Concrete Lab Equipment
Concrete Cube Testing Machine , Digital Display Concrete Lab Equipment
Concrete Cube Testing Machine , Digital Display Concrete Lab Equipment
Specifications
Brand Name :
wangtebei
Model Number :
YES YAW
Place of Origin :
China
Model :
YES-2000 YES-2000A
Max. load :
2000KN
Accuracy of testing force :
± 1% of indicated value
Upper compression platen dia. :
Φ 225mm
Lower compression platen dia. :
Φ 300mm
Distance between two platens :
320mm
Description

Introduction:

Compression testing machine (digital, computerized etc. )
YES-2000 compression testing machine is mainly used to various materials compression test. Such as cement, concrete, brick of diverse materials, rubber tray, concrete component, metal component anti-compress strength.


1, High performance load frame, with high stiffness and stability;
2, Hydraulic loading, wide speed adjusting range;
3, Digital display testing load, speed, peak value etc;
4, With overload, over voltage, over current protection function;
5, YES-2000 is manual screw to adjust test space, YES-2000A is motor to adjust test space.

Specification:

Model YES-2000 YES-2000A
Max. load 2000KN 2000KN
Accuracy of testing force ± 1% of indicated value
Upper compression platen dia. Φ 225mm
Lower compression platen dia. Φ 300mm
Distance between two platens 320mm
Compression platen dia. φ 250mm
Piston stroke 30mm
Power supply 380V± 10%, 50Hz, 3 phase
Dimension 800× 500× 1200
Weight 750Kg
Standard Accessories Loadframe, oil pressure sensor, digital meter, compression platen, manual

Why choose us?

1)Machine's quality,if you want to choose a cheap testing ma chine Maybe the quality is too bad .And you must buy the other one after you use it for a period of the time.This situation will influence your production.So the quality of the machine is so important than others.

2)Many times after-sales service is very important too.Good after-sales service representative the image of the company .After you use the machine and find some problem of machine in some respect.A good after-sales can dealing with it effectively and protect the rights of consumers.

3)The third is technical support. Because of time difference,When you need help,other place maybe is sleeping. So the effectively contact information and serve is also useful to you.

4)The last is company. In order to ensure their image, good reputation company will produce good machine.
