HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
Specifications
Brand Name :
ZHONGYI
Model Number :
HQ15EDGKA-3.5/3.81
Place of Origin :
China
MOQ :
100pcs
Price :
$0.36 100~299pcs/$0.34 300~499pcs/$0.31 ＞500pcs
Payment Terms :
T/T
Supply Ability :
10000pcs/day
Delivery Time :
1-3 workd ays
Packaging Details :
plastic bag
Pitch :
3.5mm/3.81mm
Poles :
2-24P
Screws :
M2.0.Steel.Zinc plated
Wire guard :
Phosphor bronze Ni plated
Pin header :
Brass.Tin plated
Housing :
PA66.UL94V-0
Rated voltage :
300V
Rated current :
8A
Temp range :
-30℃~+120℃
Strip length :
6~7mm
Description

2-24 poles HQ15EDGKA-3.5mm/3.81mm 28-16AWG pcb electric plug in screw terminal block connector

Pitch

3.5mm/3.81mm
Poles 2-24P
Rated voltage 300V
Rated current 8A
Withstanding voltage AC1500/1Min
Wire range 28-16AWG
Max soldering +250℃ 5 Sec
Torque 0.2Nm(1.7Lbin)


HQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWGHQ15EDGKA-3.5mm/3.81mm Plug-In Terminal Block 28-16AWG
