PXIe-4143 PXI Source Measure Unit National Instruments With 1A Output 4 SMU Channels 24V
PXIe-4143 PXI Source Measure Unit National Instruments With 1A Output 4 SMU Channels 24V
PXIe-4143 PXI Source Measure Unit National Instruments With 1A Output 4 SMU Channels 24V
PXIe-4143 PXI Source Measure Unit National Instruments With 1A Output 4 SMU Channels 24V
PXIe-4143 PXI Source Measure Unit National Instruments With 1A Output 4 SMU Channels 24V
PXIe-4143 PXI Source Measure Unit National Instruments With 1A Output 4 SMU Channels 24V
Specifications
Price :
$10,000/sets >=1 sets
Place of Origin :
China
MOQ :
one
Packaging Details :
standard packaging
Delivery Time :
Delivery time for minimum order quantity ≤ 30 days
Payment Terms :
T/T ‌L/C
Supply Ability :
100 units/day
Brand Name :
National Instruments
Model Number :
PXIe-4143
warranty :
3 months
customized support :
OEM
place of origin :
American
brand name :
National Instruments
model number :
PXIe-4143
Description
名字 国家仪器 PXIe-4143 PXI 源测量单元

国家仪器 PXIe-4143 PXI 源测量单元

PXIe-4143 (部件编号:782431-01) 源测量单元 (SMU) 集成了一个工具通道,该通道可以以16位设定点和估计分辨率提供电流或电压.用户可以利用这个输出,它可以提供高达6 V和1 A的电源,作为SMU通道的补充电源.对于需要在扫描另一个电流或电压时保持恒定电流或电压的晶体管特性测试等应用,这个模块所提供的简化,空间和成本优势可以带来显著的益处.对于并行测试应用,用户可以在单个PXI框架中使用17个NI PXIe-4143模块,从而在19英寸和4U的空间内获得17个SMU通道和17个可编程电源通道.

这个PXIe 4143 SMU的两个通道可以作为恒压源或恒流源使用,并且每个模式都有可移动的一致性限制.此外,用户可以启用SMU通道的远程感应功能,以提高被测设备输出/电压估计的准确性,适用于高精度应用.

PXIe-4143 SMU具有估算策略,通常是在双极电路标准中添加电流运动,然后进行电压响应估算.如果被测设备(DUT)具有低电阻,则采用此策略；如果DUT的内阻较高,则添加电压运动,然后估算电流反应.

电流灵敏度:10 pA
辅助电源包含:-
SMU通道数量:4
电压范围:-24 V到24 V
SourceAdapt技术:是
最大直流吸收功率:3.6 W
最大直流源功率:3.6 W
直流电流范围:-150 mA到150 mA
脉冲电流范围:-
总线连接器:PXI Express
