National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
National Instruments PXI-2533 256-Crosspoint 1-Wire PXI Matrix Switch Module with ±55 VDC for OEM Applications
Specifications
Price :
$1,000/sets >=1 sets
Place of Origin :
China
MOQ :
one
Packaging Details :
standard packaging
Delivery Time :
Delivery time for minimum order quantity ≤ 30 days
Payment Terms :
T/T ‌L/C
Supply Ability :
100 units/day
Brand Name :
National Instruments
Model Number :
PXI-2533
warranty :
3 months
customized support :
OEM
place of origin :
American
brand name :
National Instruments
model number :
PXI-2533
Description
名字 国家仪器 PXI-2533 PXI 矩阵开关模块

国家仪器 PXI-2533 PXI 矩阵开关模块

采用固态继电器(SSR)的National Instruments PXI-2533(部件编号:778572-33)是一款1-Wire,256-Crosspoint PXI矩阵开关模块.自其继电器具有无限的机械寿命以来,PXI-2533以其可靠性而闻名.该型号提供±55 VDC,30 VACrms最大开关电压,55 W最大开关功率和1 A最大开关电流.模块设计提供典型的>2 GΩ直流隔离电阻,2 µV(典型)和1 Ω(典型)的行到列总路径电阻.

在一个行到列的50 Ω系统中,NI PXI 2533可以提供>1.5 MHz(典型)单个交叉点带宽.该开关模块中的SSR具有724 µs(典型)和2.5 ms(最大)的响应时间.NI PXI-2533在1安培和<20伏切换时,可以以400个交叉点/秒的速度扫描,并且具有256个继电器的同时驱动限制.这个矩阵开关模块可以通过PXI触发线<0到7>进行触发,并且可以以1 µs到62 µs的可编程脉冲宽度生成输出触发信号,最小脉冲宽度为70 ns.

对于I/O连接,该型号配备了一个68针的SCSI型公连接器.在典型条件下,NI PXI-2533在5V时消耗8W,在3.3V时消耗1W.它是一种3U类型的,一个插槽的PXI模块,尺寸为21.6 × 2.0 × 13.0厘米.该模块可以配置为1线4 × 64矩阵拓扑结构.

交叉点:256
扫描速率:400 次/秒
总线连接器:PXI 混合
最大直流切换电流:1 A
最大直流切换电压:55 V
行数:4
继电器类型:固态
切换带宽:1.5 MHz
模式(n线):1线
组数:1
列数:64
