Specifications
Brand Name :
HEYA
Model Number :
HY-1003
Certification :
ISO9001
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
T/T,D/A,D/P,Western Union
Supply Ability :
200 pcs/week
Delivery Time :
15-20 work days
Packaging Details :
Coated with anticorrosive oil , packed in carton box
Product Name :
Die Casting Mold
Highlight :
High-Precision Uniform Textures
Tolerance :
+/-0.005mm
Hardness :
43-47 HRC
Feature :
Durable
Processing Method :
Electroforming Processing
Material :
Stainless steel, brass, aluminum, tin, and other metal alloys
Application :
Biomedical Industry
Description
Aluminum Alloy Agricultural Machinery Die Casting Molds
Precision Aluminum Alloy Die Casting Molds for Automotive Applications
We specialize in crafting aluminum alloy die casting molds tailored for auto OEMs, automotive parts manufacturers, and auto component suppliers, focused exclusively on the high-demand engine and chassis parts of vehicles. Every mold is engineered to align with the rigorous standards of the auto industry: engine parts need to withstand high temperatures and tight assembly, while chassis parts require strong load-bearing capacity. Our molds feature CAD/STEP file compatibility, ±0.005mm precision, and a 150k+ production cycle lifespan to support high-volume, consistent manufacturing of reliable auto components.
Why Our Auto Engine/Chassis Die Casting Molds Fit Your Production
Auto industry aluminum alloy parts (especially engine and chassis components) have unique demands that generic molds often fail to meet—our design targets the practical challenges you face in automotive manufacturing:
  • Precision = Safe, Stable Assembly: Engine and chassis parts connect to critical vehicle systems. Our ±0.005mm precision ensures parts fit seamlessly into vehicle assemblies, eliminating gaps that could cause rework or safety risks.
  • CAD/STEP Compatibility Saves Development Time: We import your CAD/STEP files directly, skipping conversion delays and speeding up mold production by 3-5 days.
  • High-Volume Runs Need Durable Molds: Our 150k+ cycle lifespan covers most high-volume needs, cutting mold replacement costs by 40% compared to standard molds that wear out after 80k cycles.

Agricultural Machinery Aluminum Die Cast Mold For Gearbox / Frame Parts

Core Strengths for Auto Engine/Chassis Part Manufacturing
1. Seamless CAD/STEP File Support
We accept all mainstream automotive CAD/STEP formats (AutoCAD, SolidWorks, Siemens NX) and work directly with your 3D designs. Our team reviews your files to optimize manufacturability, adjusting draft angles for engine part ribs or refining chassis part edge profiles to enhance performance. Every detail of your auto part is replicated exactly in the final mold.
2. ±0.005mm Precision for Critical Auto Components
Our molds maintain ±0.005mm tolerance for:
  • Mounting holes (to align with vehicle frames or engine blocks)
  • Structural edges (to ensure chassis parts bear weight evenly)
  • Engine part openings (ensuring no leaks or interference)
This precision reduces assembly time by 15% and ensures compliance with auto industry quality standards like IATF 16949.
3. Aluminum Alloy Optimization for Auto Needs
Our molds are tailored to work with automotive-grade aluminum (Al-Si-Mg alloys), optimizing injection parameters to:
  • Enhance part strength (critical for chassis load-bearing)
  • Improve heat resistance (vital for engine parts)
  • Reduce porosity (avoiding fluid leaks in engine components)
4. 150k+ Cycles for High-Volume Auto Production
Our high-wear-resistant steel molds (52-54 HRC hardness) maintain precision through 150k+ cycles, meaning:
  • One mold can cover production of a full vehicle model year
  • No mid-cycle mold changes that cause 4-6 days of downtime
  • Consistent part quality from first to last unit
Technical Specifications
Specification Details Value for Your Auto Production
Dimensional Precision ±0.005mm (mounting holes, edges, structural features) Ensures safe, seamless assembly into vehicles; cuts rework
CAD/STEP Compatibility AutoCAD, SolidWorks, Siemens NX (direct import) Speeds up mold development for new vehicle models
Production Cycles 150k+ (with regular maintenance) Supports high-volume runs; reduces mold replacement costs
Aluminum Alloy Compatibility Optimized for Al-Si-Mg (automotive-grade aluminum) Produces strong, heat-resistant parts for engines/chassis
Mold Material High-wear steel (52-54 HRC) Maintains precision over long production cycles

Agricultural Machinery Aluminum Die Cast Mold For Gearbox / Frame Parts


Quality Assurance for Auto Manufacturing
Our mold production follows a standardized workflow tailored to automotive needs. We test steel hardness and wear resistance before machining, use Zeiss CMM tools to verify ±0.005mm precision, and run 50+ test injections with automotive-grade aluminum. We provide traceable records—material certificates, inspection logs—to help you meet auto industry supply chain audit requirements.
Our Automotive Partners
  • Auto OEMs: Manufacturing key engine/chassis parts for new vehicle models
  • Automotive Parts Manufacturers: Producing aftermarket or OE replacement components
  • Auto Component Suppliers: Creating niche parts for heavy-duty trucks or high-performance vehicles
Bring Your Auto Part Design to Life
Upload your CAD/STEP file to receive a free DFM report with optimization tips and a detailed quote within 24 hours. We'll adjust any details to ensure the mold fits your high-volume auto production goals.
