35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
Specifications
Place of Origin :
Shandong, China
Brand Name :
Yuanhui
Model Number :
YJLV YJLV22 YJLV32
MOQ :
100 meters
Price :
$3.25/meters 100-999 meters
Certification :
ISO CE CCC
Payment Terms :
T/T
Supply Ability :
50000 meters per week
Delivery Time :
5-7 work days
Packaging Details :
Ironwood shaft packing
Insulation Material :
lszh XLPE
Type :
LOW VOLTAGE High Voltage Medium Voltage
Application :
Industrial construction underground power station
Conductor Material :
Aluminum
Jacket :
PVC
Size :
as requirments
Product name :
YJV YJV22 YJV23 XLPE Power Cable
Rated voltage :
1-35KV 0.6/1KV
Standard :
IEC 60227
Certificate :
ISO9001/CCC/CE
Core :
1/2/3/4/3+1/5/3+2/4+1
Package :
Iron-wooden Drum
Length :
Customized Meters
Armour :
SWA STA AWA ATA
Cross section :
1.5mm-600mm2
Sample :
Availaible
Description
16/25/35mm 2/3/4 Core Aluminum Power Cable for Industrial Construction Project
Product Description
1. Conductor Material and Sizes
This aluminum power cable is designed for industrial construction projects. It comes in three different cross-sectional sizes: 16mm², 25mm², and 35mm². The use of aluminum as the conductor material offers several advantages. Aluminum is a cost-effective alternative to copper while still providing good electrical conductivity. It is lightweight, making it easier to handle and install, especially in large-scale construction projects where cables need to be routed over long distances.
2. Number of Cores
The cable is available in 2-core, 3-core, and 4-core configurations. The choice of the number of cores depends on the specific electrical requirements of the industrial construction project. For example, a 2-core cable might be used for single-phase power supply, while a 3-core or 4-core cable could be used for three-phase power distribution.
3. Industrial Construction Applications
This power cable is ideal for a wide range of industrial construction applications. In industrial settings, reliable power supply is crucial for the operation of machinery, equipment, and lighting systems. The cable can be used to connect power sources to various electrical loads within the construction site, such as motors, pumps, welders, and other power tools.
It is also suitable for outdoor installations, as it is designed to withstand harsh environmental conditions. The cable's insulation and sheath provide protection against moisture, dust, and mechanical damage, ensuring long-term durability and reliable performance.
4. Quality and Reliability
When it comes to industrial construction projects, quality and reliability are of utmost importance. This aluminum power cable is manufactured to meet strict industry standards, ensuring its performance and safety. The insulation material used is of high quality, providing excellent electrical insulation properties and reducing the risk of electrical faults.
The cable is also tested for durability and strength to ensure it can withstand the rigors of industrial construction environments. With its reliable construction and quality materials, this power cable is a trusted choice for industrial construction projects.
Specification

Norminal cross

section

 Reference overall diameter of cable Permissible A mpacily Reference weight of cable
A
In air In ground
MM² MM CU AL CU AL Kg/km
4X2.5 11.8 29 22 38 29 211 148
4X4 13.0 38 29 50 38 283 182
4X6 14.2 49 37 62 47 376 225
4X10 16.7 67 50 84 63 567 314
4X16 19.1 88 66 109 82 829 424
4X25 23.2 119 90 142 107 1249 618
4X35 25.5 146 110 170 129 1689 804
4X50 26.2 173 128 201 151 2146 916
4X70 28.9 218 164 245 185 2944 1219
4X95 32.5 271 201 294 223 3903 1559
4X120 35.9 315 234 333 253 4967 1956
4X150 40.2 366 272 374 321 6133 2413
4X185 44.4 422 315 421 481 7600 3008
4X240 49.4 486 377 489 425 9743 3784
4X300 56.0 569 440 555 12271 4716
4X400 67.9 686 628 16248

Packing & Delivery
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Shandong Jinyu Cable Co., Ltd. is located in Yanggu, the ancient city of a thousand years, the capital of Dongyi and the hometown of Wusong. It is adjacent to the Yellow River in the south, Shuicheng in the north, the German-Shanghai Expressway in the west, the Beijing-Kowloon High-speed Railway to the east, and the Beijing-Hangzhou Grand Canal running through the entire territory. The company integrates scientific research, production, and sales. It produces power cables, high-voltage cables, overhead cables, control cables, flame-retardant and fire-resistant cables, low-smoke and halogen-free cables and other products. The production equipment, complete testing equipment, dozens of varieties and hundreds of specifications of products are sold well at home and abroad and are trusted by users.The company adheres to the brand strategy, exerts the advantages of the Yanggu cable brand, and the Ever bright Yanggu Yuanhui cable brand. All the staff wholeheartedly welcome you to come to the company for guidance and business negotiation!
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
35mm Aluminum 2 Core Power Cable underground For Industrial Construction
FAQ
1. What is the minimum order quantity?
If you insist on buying one piece, or you only need one piece, we are likely to produce MOQ for you in batches.
2. How to get samples to check the quality? How long can I get the samples?
After the price is confirmed, samples can be provided for your evaluation. After confirming the sample details, the samples will be ready for delivery within 3-7 days, and sent to you by courier, and arrive within 3-5 days.
3. Which payment method does your company accept?
We accept wire transfer, letter of credit, Western Union.
4. What are your company's shipping terms and delivery time?
20-30 days for bulk, 5-10 working days for inventory.
5.Do you have a discount?
We will do our best to provide you with these services at the best price and quality service.
