XDZ-1-l／18 Standard type hard rod high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Specifications
Brand Name :
OEM
Model Number :
XDZ-1
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
200
Packaging Details :
Wooden box packing
Voltage :
2500V
energy :
20J
Spark frequence :
12-14times /S
frame size :
300*200*120
ignition rod :
M18*1.0 M18*1.5 M27*1.5
temperature :
1300℃
rod dia :
Φ16 Φ18
Description
XDZ-1-l／18 Standard Type Hard Rod High Energy Ignition Gun
The XDZ-1-l／18 is a standard type hard rod high energy ignition gun designed for reliable industrial ignition applications.
Product Series
Sr. Model Description
1XDZ-1-l/dStandard type hard rod high energy ignition gun
2XDZ-1-l/d BStandard type hard rod explosion-proof high-energy igniting gun
3XDZ-1-l/d KStandard type hard gun handle high energy ignition gun
4XDZ-1R-l/dStandard type soft rod high energy ignition gun
5XDZ-1R-l/d BStandard type soft rod explosion-proof high-energy igniting gun
6XDZ-2-l/dNon standard hard rod high energy ignition gun
7XDZ-2-l/d BNon standard hard rod explosion-proof high-energy igniting gun
8XDZ-2R-l/dNon standard soft rod high energy ignition gun
9XDZ-2R-l/d BNon standard soft rod explosion-proof high-energy igniting gun
10XDZ-3-l/dSpecial electric nozzle high-energy igniting gun
11XDZ-3-l/d BExplosion proof special electric nozzle high-energy igniting gun
12XDZ-4-l/d BThe hard rod high clearance point guns
Notes:
  • In the table type code "l" is igniting gun length, in unit mm
  • In the table "d" is igniting gun diameter, available in 14mm, 16mm, 18mm series
  • Custom design and production available according to user requirements
Performance Parameters
Parameter Name Unit Data
Starting ignition voltageVDC600～1400
Center electrode resistanceΩ≤0.1
Firing end long-term temperature℃≤800
Firing end short-time (<5min) temperature resistance℃1250
Outline and Mounting Dimensions
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-1, XDZ-1-l／18 Standard type hard rod high energy ignition gun (L≤1000mm)
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-2, XDZ-1-l／18 Standard type hard rod high energy ignition gun (L＞1000mm)
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-3, XDZ-1-l/d B Standard type hard rod explosion-proof high-energy igniting gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-4, XDZ-1-l／18 K Standard type hard gun handle high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-5, XDZ-1R-l／18 Standard type soft rod high energy ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-6, XDZ-3 Catalytic plug ignition gun
XDZ-1-l／18 Standard type hard rod high energy ignition gun
Drawing 3-7, XDZ-4-l／d hard rod high pressure gap ignition gun
