Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Q62AD-DGH Mitsubishi Universal Model Redundant Power Supply Module 100 To 240 V AC
Specifications
Brand Name :
MITSUBISHI
Model Number :
Q62AD-DGH
Place of Origin :
Japan
MOQ :
1
Price :
Negotiations
Delivery Time :
5-8 working days
Packaging Details :
New original box
Basic Operation Processing Speed (LD Instruction) :
0.12 μs
Input :
100 To 240 V AC
Output :
5 V DC/3 A
Type :
Redundant Power Supply Module
Description

Product Description

Q62AD-DGH Mitsubishi Universal model Redundant Power Supply Module


Q62AD-DGH Description

The Mitsubishi Electric Q62AD-DGH is a high-speed analog-to-digital converter module designed for use with the MELSEC-Q series of Programmable Logic Controllers (PLCs). This module acts as a critical interface between the digital world of the PLC and the analog world of field instruments. It receives standard analog voltage or current signals (e.g., 0-10V, 4-20mA) from sensors or measuring devices and converts them into high-resolution digital values that the PLC CPU can process for monitoring, control, and data logging applications. It is known for its high accuracy, reliability, and fast conversion speed, making it suitable for demanding industrial automation processes in fields like factory automation, environmental monitoring, and precision machining.

Q62AD-DGH Characteristics

  • •
    ​​High-Speed Conversion:​​ Capable of converting analog signals to digital values at high speed, allowing for rapid system response to process changes.
  • •
    ​​High Resolution:​​ Offers 16-bit resolution, providing fine measurement precision and allowing the PLC to detect very small changes in the analog signal.
  • •
    ​​Multi-Channel Input:​​ The Q62AD-DGH provides 4 independent analog input channels, allowing a single module to connect to multiple sensors, which saves space and reduces cost compared to using single-channel modules.
  • •
    ​​Flexible Input Types:​​ Each channel can be individually configured to accept different analog signal types, including:
    • •
      DC Voltage: e.g., 0-10V, ±10V
    • •
      DC Current: e.g., 4-20mA, 0-20mA
  • •
    ​​Easy Configuration and Scaling:​​ Settings such as input range selection and scaling are configured easily using the GX Works2 or GX Works3 engineering software, simplifying setup and integration into the control program.
  • •
    ​​High Reliability:​​ Designed for harsh industrial environments with robust construction and high noise immunity, ensuring stable operation.

Q62AD-DGH Material & Application

  • •
    ​​Materials:​​ The module is constructed with a robust metal casing and uses industrial-grade electronic components on a PCB. The terminal block is typically made of heat-resistant, flame-retardant plastic.
  • •
    ​​Primary Applications:​​
    • •
      ​​Process Control:​​ Reading process variables like temperature, pressure, flow, and level from transmitters.
    • •
      ​​Factory Automation:​​ Monitoring analog signals from sensors for position, speed, tension, and weight.
    • •
      ​​Environmental Monitoring Systems:​​ Measuring data from sensors for humidity, gas concentration, or light intensity.
    • •
      ​​Test and Measurement Equipment:​​ Digitizing analog outputs from various test apparatus.

Q62AD-DGH Important Parameters

The key specifications for the Mitsubishi Q62AD-DGH are summarized in the table below.
Parameter
Specification
​​Model​​
Q62AD-DGH
​​Product Type​​
Analog to Digital Converter (A/D) Module
​​Series​​
MELSEC-Q Series
​​Number of Channels​​
4 channels
​​Input Signal​​
DC Voltage / DC Current (selectable per channel)
​​Voltage Input Ranges​​
0-10V, 0-5V, ±10V, ±5V, 1-5V
​​Current Input Ranges​​
0-20mA, 4-20mA
​​Resolution​​
16-bit (1/32000 scale)
​​Conversion Speed​​
80 µs/channel (80 microseconds per channel)
​​Accuracy​​
±0.1% (of full scale) for voltage inputs; ±0.2% for current inputs
​​Digital Output Value​​
-32000 to +32000, 0 to 32000, 0 to 16000 (selectable based on range)
​​Isolation Method​​
Photocoupler isolation between analog I/O and PLC, and between channels
​​Required Power​​
5V DC (from main base unit or power supply module)



性能仕様

入力仕様
アナログ入力点数
アナログ入力 電流
二線式伝送器用電源部 供給電圧
最大供給電流
短絡保護
チェック端子
デジタル出力
入出力特性,分解能 入力レンジ
電流入力 4～20mA
4～20mA(拡張モード)
ユーザレンジ設定
精度(デジタル出力値の最大値に対する精度) 基準精度
温度係数
A/D変換速度
絶対最大入力 電圧
電流
共通仕様
絶縁方式
絶縁耐圧
絶縁抵抗
外部供給電源 電圧
電流
外部配線接続方式
入出力占有点数
DC5V内部消費電流
外形寸法 高さ(H)
幅(W)
奥行き(D)
質量

2点(2チャンネル)
DC4～20mA(入力抵抗値:250Ω)
DC26±2V
DC24mA
あり(制限電流:25～35mA)
あり
分解能16ビット:-768～+32767
分解能32ビット:-1536～+65535
デジタル出力値(分解能)
16ビット:0～32000(500.0nA)
32ビット:0～64000(250.0nA)
32ビット:-16000～72000(250.0nA)
16ビット:0～32000(303.2nA)
32ビット:0～64000(151.6nA)
±0.05％
±71.4ppm／℃(0.00714％／℃)
10ms／2チャンネル
±15V
±30mA

入出力端子とシーケンサ電源間:フォトカプラ絶縁
アナログ入力チャンネル間:トランス絶縁
外部供給電源とアナログ入力間:トランス絶縁
入出力端子とシーケンサ電源間,アナログ入力チャンネル間,外部供給電源とアナログ入力間:AC1780Vrms／3サイクル(標高2000m)
入出力端子とシーケンサ電源間,アナログ入力チャンネル間,外部供給電源とアナログ入力間:DC500V　10MΩ以上
DC24V(+20/-15％,リップル,スパイク500mVp-p以下)
0.19A(突入電流:5.5A,200µs以下)
18点ネジ端子台(M3ネジ)
16点(I/O割付:インテリ 16点)
0.33A
98mm
27.4mm
112mm
0.19kg
