Four Wheels Electric Shuttle Bus 23 Seats With Door / Electric Mini Bus AC Motor
Four Wheels Electric Shuttle Bus 23 Seats With Door / Electric Mini Bus AC Motor
Four Wheels Electric Shuttle Bus 23 Seats With Door / Electric Mini Bus AC Motor
Four Wheels Electric Shuttle Bus 23 Seats With Door / Electric Mini Bus AC Motor
Specifications
Brand Name :
LANGJIE
Model Number :
LQF1024F
Certification :
CE
Place of Origin :
GUANGZHOU ,CHINA
MOQ :
1 UNIT
Price :
Negotiated
Payment Terms :
T/T
Supply Ability :
300 UNITS PER MONTH
Delivery Time :
20-25 WORKING DYA
Packaging Details :
NUDE PACKING
Part Name :
Electric Luggage Cart
Color :
White
Passenger capacity :
5 seats
Max.Speed :
30 km/h
Range(loaded) :
70 km
Qty/40'GP (Aassembled) :
3 unit (assembly )
Recharge time :
8~10 h
Quality :
Original Quality
Steering :
Left
Recharge Time :
8-10h
Description
Electric Passenger Bus 5 Seats Freight Car AC Motor With CE Approved Certoficate For Hotel

Model LQF1024F Electric Freight Car 5 Seats Specifications :

HS CODE8709119000
Qty/20'GP (Assembled)1 unit
Qty/40' GP(Assembled)2 units
Specifications
Performance:
Passenger capacity5 seats
Range(loaded)70km
Max.Speed≤30m/h
Climbing Ability(loaded)≤20%
Braking Distance≤5m
Min.Turning Radius≤4.5m
Recharge time8~10h
Dimensions
L×W×H4190*1560*2010mm
L×W×H cargo size1500*1500*300mm
Axle Distance2020mm
Vehicle Weight1080kg
Max. loading900kg
Standard Configurations
Motor48V/5 KW AC motor
Controller48V
BatteryMaintenance-free battery 6V/170Ah*8pcs
Body & RoofThe high-strength composite material body (PP composite material injection-molded front hood) has excellent impact resistance./Enhanced composite material and aluminum alloy frame; lightweight, resistant to aging, and not prone to fading.
WindshieldSee-through Laminated glass
SeatsPU car seat, ergonomic, adjustable structure for driver's seat.
Rear view mirror2pcs
TireVacuum radial tire 165/70R13, steel rim
ChassisHigh-strength steel frame longitudinal beam chassis with electrophoresis and powder coating rust prevention treatment
SteeringDual-pinion rack and pinion steering with electric speed-sensitive power assistance system
Front SuspensionFront MacPherson independent suspension, with coil springs and telescopic hydraulic shock absorbers.
Rear suspensionIntegral rear axle with leaf springs and telescopic hydraulic shock absorbers
Lighting systemLED headlights, fog lights, turn signals, taillights, horn, reversing alarm
Brake systemFront ventilated disc rear drum hydraulic dual circuit braking system with handbrake parking, equipped with vacuum power-assisted brakes
ChargerIntelligent high-frequency vehicle charger. Input voltage 220V, output 48V/25A.
DashboardInjection-molded dashboard with a combination switch, electric lock switch, emergency power-off switch, and multifunctional LCD display (showing indicators for voltage, battery level, speed, mileage, etc., and an entertainment playback system). It is equipped with USB/Type-C ports, storage compartments, and a cup holder.


Product showing:
Four Wheels Electric Shuttle Bus 23 Seats With Door / Electric Mini Bus AC Motor


FAQ
1, What's the production time?
Normally for 30 working days
2, What's your payment term?
T/T 30% deposit and balance paid before shipment
3, Can we also purchase the parts
Yes,if you do maintainess service,you can also buy parts from us.We are the profeesional for the aftersales,
4, How do you provide after-sales once customer bought the cart from us?
Once you purchase the cart from us,then i will provide you manual to learn it and tell you how to fix it.
5.What is your MOQ?
You can order MOQ 1 unit .
6,Can we put the Logo we designed on the cart?
Yes, you can put your own Logo on the cart.
7,How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from.
