Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
Specifications
Brand Name :
ZOZHI
Model Number :
MS-100L2-4
Certification :
CCC, CE
Place of Origin :
China
MOQ :
1pc
Price :
$35.3~$45.5
Payment Terms :
L/C, T/T
Supply Ability :
10000pcs/month
Delivery Time :
25 working days after received your payment
Packaging Details :
Packed in cartons,veneer case or wooden case.
Type :
Asynchronous Motor, Induction Motor
Frequency :
50HZ
Phase :
3 Phase Induction Motor
Protect Feature :
Totally Enclosed
AC Voltage :
220V,380V or on request
Efficiency :
IE1,IE2
Model Name :
MS
Power :
3KW/4HP
Structure :
Asynchronous Motor
Protection Class :
IP44/IP54
Color :
Black or Customers' Request
Material :
Aluminum Housing
Winding :
Aluminium or copper
Description

3 Phase Induction Motor

MS100L2-4

3KW/4HP

1400RPM

MS series three-phase induction Aluminum frame housing motors are developed with techniques, are renewal and upgrading series.

Feature: Induction motor has outstanding performance, such as High efficiency, energy-saving, high starting torque, low noise, little vibration, reliable operation, easy maintenance, etc.


Usable range: MS series motors are widely used in places where not exists combustible, explosive, or corrosive gas, and without any special requirements, such as machine tools, pumps, fans, transport machinery, mixer, agriculture machinery, food machines, etc.

Technical data

Model Power (V) (HZ) Current (A) Power Factor

Eff

(%)

 Speed (r/min)

Tstart/

Tn

Tmax/

Tn

Ist/

In
HP KW
MS561-2 0.12 0.09 380 50 0.3 0.76 60 2750 2.3 2.4 6
MS562-2 0.16 0.12 0.37 0.78 63 2750 2.3 2.4 6
MS631-2 0.25 0.18 0.53 0.75 69 2800 2.2 2.4 4.5
MS632-2 0.33 0.25 0.68 0.78 72 2800 2.2 2.4 4.5
MS711-2 0.5 0.37 0.98 0.8 73 2800 2.2 2.4 4.5
MS712-2 0.75 0.55 1.35 0.82 75 2800 2.2 2.4 4.5
MS801-2 1 0.75 1.75 0.85 76 2800 2.2 2.4 4.5
MS802-2 1.5 1.1 2.55 0.85 77 2800 2.2 2.4 4.5
MS90S-2 2 1.5 3.36 0.87 78 2800 2.2 2.4 4.5
MS90L-2 3 2.2 4.93 0.87 78 2800 2.2 2.4 5
MS100L-2 4 3 6.31 0.87 83 2880 2.3 2.4 7
MS112M-2 5.5 4 8.12 0.88 85 2890 2.3 2.4 7
MS132S1-2 7.5 5.5 11 0.88 86 2900 2.3 2.4 7
MS132S2-2 10 7.5 14.9 0.88 87 2900 2.3 2.4 7
MS160L-2 25 18.5 34.7 0.9 90 2930 2.3 2.4 7
MS561-4 0.08 0.06 0.27 0.68 50 1300 2.2 2.3 5.5
MS562-4 0.12 0.09 0.36 0.7 54 1300 2.2 2.3 5.5
MS631-4 0.16 0.12 0.48 0.63 60 1400 2.2 2.4 4.5
MS632-4 0.25 0.18 0.65 0.66 64 1400 2.2 2.4 4.5
MS711-4 0.33 0.25 0.83 0.68 67 1400 2.2 2.4 4.5
MS712-4 0.5 0.37 1.12 0.72 69 1400 2.2 2.4 4.5
MS801-4 0.75 0.55 1.56 0.73 73 1400 2.2 2.4 4.5
MS802-4 1 0.75 2.01 0.75 75 1400 2.2 2.4 4.5
MS90S-4 1.5 1.1 2.83 0.78 76 1400 2.3 2.4 5
MS90L-4 2 1.5 3.84 0.78 76 1400 2.2 2.4 5
MS100L1-4 3 2.2 4.2 0.75 75 1400 2.2 2.4 5
MS100L2-4 4 3 6.78 0.82 82 1410 2.3 2.4 7
MS112M-4 5.5 4 8.82 0.82 84 1435 2.3 2.4 7
MS132S-4 7.5 5.5 11.8 0.83 85.5 1445 2.3 2.4 7
MS132M-4 10 7.5 15.6 0.84 87 1445 2.3 2.4 7
MS711-6 0.24 0.18 0.74 0.66 56 900 2 2.2 5.5
MS712-6 0.33 0.25 0.95 0.68 59 900 2 2.2 5.5
MS801-6 0.5 0.37 1.3 0.7 62 900 2 2.2 5.5
MS802-6 0.75 0.55 1.79 0.72 65 900 2 2.2 5.5
MS90S-6 1 0.75 2.29 0.72 69 910 2.1 2.2 5.5
MS90L-6 1.5 1.1 3.18 0.73 72 910 2.1 2.2 5.5
MS100L-6 2 1.5 3.89 0.76 76 940 2.1 2.2 5.5
MS112M-6 3 2.2 5.57 0.76 79 940 2.2 2.3 6.5
MS132S-6 4 3 7.4 0.76 81 960 2.2 2.3 6.5
MS132M1-6 5.5 4 9.75 0.76 82 960 2.2 2.3 6.5
MS132M2-6 7.5 5.5 12.9 0.77 84 960 2.2 2.3 6.5

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Reviews from the client:

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Shipping:

after 25~30days, we will deliver the goods, for loose goods better packed by the pallet for avoiding destroy

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

​

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4

Aluminum 3KW 1400RPM Three Pahse Induction Motor MS-100L2-4
