This low‑height skylight abandons large‑height arched shell structure, adopts thin‑integrated layout. It can be installed on roof ridge or roof slope position. For old‑factory reconstruction, it does not need large‑scale modification of original roof structure. Under normal working condition, sash opens for hot‑air exhaust; when fire alarm signal comes, sash opens rapidly for smoke‑vent; when raining, sash closes to guarantee roof waterproof performance. Modular splicing can match different ventilation‑volume requirements.

Hot‑dip galvanized steel profile, compact height design, reduce whole‑unit wind‑load area, good stability under strong‑wind environment.

Two optional schemes: translucent anti‑UV FRP / polycarbonate panel for daylighting; or galvanized steel plate for non‑daylighting ventilation‑only requirement.

Compact‑stroke electric push‑rod matches low‑height sash structure; with manual emergency opening mechanism for power‑off emergency condition.

Integral water‑collecting trough structure, collect rainwater and condensate water, avoid water penetration at roof‑connection position, specially optimized for old‑roof reconstruction waterproof risk.

Continuous aging‑resistant EPDM sealing strips around sash gap, lower rain‑splash and dust‑infiltration risk under closed state.

• Ultra‑thin low‑height profile, suitable for projects with roof height‑limit that cannot adopt conventional high skylight
• Small wind‑bearing area, excellent wind‑resistance performance for strong‑wind‑area projects
• Specially optimized for old‑factory renovation, less modification for existed roof structure
• Optional daylighting / non‑daylighting version, satisfy different workshop functional demands
• Integrated drainage base, effectively reduce leakage risk for reconstruction‑project roof opening
• Support natural ventilation and fire‑alarm linkage smoke‑exhaust, meet multi‑dimension building‑code requirements

1. Raw‑material incoming inspection for steel profile, panel and driving accessories.
2. CNC cutting, bending and welding for thin‑type frame and drainage‑base.
3. Hot‑dip galvanizing anti‑corrosion treatment for steel components.
4. Panel cutting and sealing‑strip pre‑assembly.
5. Push‑rod and control‑circuit pre‑assembly & debugging inside factory.
6. Whole‑unit opening‑closing and waterproof simulation test before delivery.
