MachineU > China Products > Tools & Hardware > Pumps & Parts > Pumps
A4VSO355DRG/30L-PPB13N00 German made Rexroth hydraulic piston pump
A4VSO355DRG/30L-PPB13N00 German made Rexroth hydraulic piston pump
Specifications
Model Number :
A4VSO355DRG/30L-PPB13N00
Delivery Time :
2 weeks
Max. Speed (at Vg max)​ :
1500 rpm (A4VSO355 size)
MOQ :
1
Packaging Details :
wooden box
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Min. Inlet Pressure​ :
0.8 ~ 2 bar absolute (self-priming, avoid cavitation)
Hydraulic Fluid​ :
Mineral oil (HL/HLP per DIN 51524); HFC only with V-seal version
Nominal Pressure​ :
350 bar (35 MPa)​
Supply Ability :
100
Nominal Flow​ :
≈ 533 L/min @ 1500 rpm (Vg max)
Brand Name :
Rexroth
Certifiion :
ISO
Place of Origin :
German
Description

Parameter

Specifiion

Manufacturer / Series​

Rexroth A4VSO Series – Swashplate Axial Piston Variable Displacement Pump, Open Circuit

Model Code​

A4VSO355 DRG / 30L-PPB13N00

Size (Nominal Displacement)​

355 cm³/rev (Vg max)

Circuit Type​

Open Circuit

Control Type​

DRG – Pressure Compensator with Remote Pressure Setting​ (Pressure limiting control + pilot port X for remote adjustment of cut-off pressure)

Series​

30 Series

Rotation​

L – Counter-Clockwise​ (viewed from shaft end)

Shaft​

P – Metric parallel keyed shaft (plain shaft with key, DIN/ISO)

Mounting Flange​

B – ISO 4-bolt flange

Working Ports​

13 – Side ports with metric BSPP (G) threads (Suction S & Pressure B offset 90°)

Through-Drive / Aux Pump​

N00 – No through-drive, no auxiliary pump

Seal Material​

P – NBR (Nitrile, for mineral oil HLP); V = FKM(Viton) for HFC-compatible versions

Nominal Pressure​

350 bar (35 MPa)​

Peak / Max Pressure​

400 bar (40 MPa)​

Max. Speed (at Vg max)​

1500 rpm (A4VSO355 size)

Nominal Flow​

≈ 533 L/min @ 1500 rpm (Vg max)

Min. Inlet Pressure​

0.8 ~ 2 bar absolute (self-priming, avoid cavitation)

Hydraulic Fluid​

Mineral oil (HL/HLP per DIN 51524); HFC only with V-seal version

Viscosity Range​

10 – 1000 mm²/s (opt. 16–100 mm²/s)

Weight (approx.)​

~207 kg

Origin​

Germany

A4VSO355DRG/30L-PPB13N00 German made Rexroth hydraulic piston pump

R910904555 A4VSO71LR2/10R-PPB13N00
R910974769 A4VSO250DR/30R-PPB13N00
R910976965 A4VSO250DRG/30R-PPB13N00
R910978355 A4VSO250LR2N/30R-PPB13N00
R910985297 A4VSO250LR2/30R-PPB13N00
R910985509 A4VSO250DFR/30R-PPB13N00
R910998618 A4VSO180DFR/30R-PPB13N00
R910999125 A4VSO180DR/30R-PPB13N00
R910999730 A4VSO125LR2N/30R-PPB13N00
R910999906 A4VSO180LR2/30R-PPB13N00
R910999362 A4VSO125DR/30R-VPB13N00
R902404170 A4VSO180DR/30R-VPB13N00
R902404170 AA4VSO180DR/30R-VPB13N00
R910977292 AA4VSO250LR2D/30R-PPB13N00
R902445995 AA4VSO500HS4/30R-PPH25N00
R902481044 A4VSO500DP/30R+A4VSO500DP/30R
R902404170 AA4VSO180DR/30R-VPB13N00
R902423294 AA4VSO71DR/10R-PPB13N00
R902430589 A4VSO180DFE1/30R-PPB13N00
R902432803 A4VSO125DFE1/30R-PPB13N00
R902445995 AA4VSO500HS4/30R-PPH25N00
R902447959 A4VSO71DFE1/10R-PPB13N00
R902454219 A4VSO40DFE1/10R-PPB13N00
R902481044 A4VSO500DP/30R+A4VSO500DP/30R
R910904555 A4VSO71LR2/10R-PPB13N00
