R900935659 DBW20B1-5X/200-6EG24N9K4 German Made Electromagnetic Relief Valve Rexroth
Rexroth DBW20B1-5X/200-6EG24N9K4 — Pilot-Operated Solenoid Relief Valve (P/N: R900935659)

German-made electromagnetic relief valve featuring pilot-operated pressure relief with integrated solenoid unloading functionality.

Technical Specifications
Parameter Value
Part Number R900935659
Model DBW 20 - B1 - 5X / 200 - 6EG24N9K4
Valve Type Pilot-operated pressure relief valve with integrated solenoid unloading (DBW series)
Nominal Size (NG) 20 — subplate mounting per ISO 6264 / NG20
Function Pressure limiting at set value + solenoid-actuated system unloading (energize → P→T open, system near 0 bar)
Adjustment Type B1 = Hexagon socket setscrew with protective cap (Allen key adjustable; B-version has different pilot damping orifice vs A-version)
Component Series 5X (series 50-59, dimensionally interchangeable)
Max. Adjustable Relief Pressure 200 bar (adjustment range typically 4-200 bar)
Max. Operating Pressure (P-port) 350 bar
Max. Flow Rate (Qmax) approx. 500 L/min (Size 20 DB/DBW series)
Pilot Oil Internal pilot supply, internal pilot drain (standard DBW)
Solenoid Type Wet-pin DC solenoid
Solenoid Voltage 24 V DC (G24)
Electrical Connection Plug-in socket per EN 175301-803 Form A (K4 = mating plug sold separately)
Manual Override N9 = concealed push-button manual override on coil
Seal Material NBR (standard, for mineral oil HL/HLP, HFC)
Hydraulic Fluid Mineral oil HL, HLP per DIN 51524; HFC (water-glycol); HLPD, HVLP, HVLPD
Fluid Temperature Range -30 °C to +80 °C (NBR seals)
Viscosity Range 10-800 mm²/s
Weight (approx.) 7.9 kg
Body Material Cast iron / steel, zinc-plated
R900935659 DBW20B1-5X/200-6EG24N9K4 German made electromagnetic relief valve Rexroth
Frequently Asked Questions
Q1: What is the difference between A1 and B1 versions (DBW20A1 vs DBW20B1)?
Both are subplate-mounted pilot relief valves with solenoid unload and identical adjustment method (hex socket + cap). The B1 version has a different pilot-stage damping orifice — it provides slightly different dynamic response (pressure overshoot/settling) vs A1. Pressure range, flow rating, solenoid, and mounting are identical. A1 is the general-purpose default; B1 is selected when system stability/damping tuning is required.
Q2: Is this direct-acting or pilot-operated?
It is a pilot-operated (two-stage) relief valve with solenoid unloading. A pilot stage controls the main spool for stable high-flow relief; the integrated solenoid can command the valve to dump system pressure to tank.
Q3: How do I adjust the relief pressure?
With system depressurized, remove the protective cap, turn the setscrew with an Allen key — clockwise to increase, counterclockwise to decrease. Factory preset is typically near minimum of the spring range. Reinstall cap and verify with a pressure gauge. The solenoid does NOT change the set pressure.
Q4: What is the solenoid logic?
Standard: Solenoid DE-energized = relief active at set pressure. Solenoid ENERGIZED = system unloaded (P connected to T, near tank pressure). Confirm this matches your control logic before wiring.
Q5: Which subplate and electrical connector are needed?
  • Subplate: standard NG20 (ISO 6264) with P and T ports (G 3/4" BSP or M27×2 on subplate), four M12 bolts @ ~70-80 N*m
  • Electrical: EN 175301-803 Form A (DIN 43650-A) 3-pin + PE connector, 24 V DC. If the plug has LED indication, observe (+) / (-) polarity markings
Q6: Common faults & causes?
  • Solenoid clicks but system does NOT unload: pilot orifice clogged, main spool stuck, no coil current (check ~18-28 Ω), manual override jammed
  • Pressure won't reach set value / creeps early: wrong spring (not /200), pilot damping hole blocked, contaminated pilot seat, excessive T-backpressure (internal pilot drain)
  • Coil overheats / burnt smell: overvoltage (>10% above 24V), wrong voltage coil fitted — replace only with correct G24 wet-pin coil
  • Chatter / unstable: air in system, high T-backpressure, worn pilot seat — bleed air first
Q7: Does T-port backpressure affect set pressure?
Yes — this model has internal pilot drain. Backpressure at T adds 1:1 to the relief setpoint. If your tank line has >5 bar sustained backpressure, consider the DBW…Y version (external pilot drain to separate tank line).
Q8: Fluid & seal compatibility?
NBR seals = mineral oil (HL/HLP) & HFC (water-glycol). For HEES/HETG biodegradable oils or HFD phosphate ester → specify FKM (Viton) seal variant. Maintain oil cleanliness per ISO 4406 code 18/16/13 or better.
