12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
Specifications
Brand Name :
JCYC
Model Number :
THP
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
$41.6-$329.9/pc
Payment Terms :
T/T
Supply Ability :
5000 pcs/per mouth
Delivery Time :
5 work days
Packaging Details :
1.Inner package: bubble film or stretch film. 2.Outside package: cartons or wooden cases.
Product Name :
12v 24v Electric Car Winch
Rated line pull :
2000-20000lbs
Voltage :
12/24v
Battery Cable :
72mm
diameter :
31-38mm
Fairlead :
4-Way Roller Fairlead
Cable :
13mmx36m
Description
12v 24v Electric Car Winch

The electric car winch is a compact and powerful pulling device widely used for rescuing stuck vehicles, towing, and handling heavy loads. It is especially suitable for ATVs, UTVs, off-road vehicles, and light trucks.

Powered by a 12V DC power supply, the winch can be conveniently operated directly from the vehicle battery, eliminating the need for extension cords or small gasoline engines. It is equipped with either a permanent magnet DC motor or a wound motor, providing high torque output and fast line speed for reliable performance under heavy loads.

The winch features a specially designed planetary gear system, ensuring high efficiency, smooth operation, and strong load-bearing capability. A solenoid control box is supplied as standard, offering stable and safe electrical control.

With its compact structure, durable design, and easy operation, the ATV electric winch is an ideal solution for vehicle recovery, off-road adventures, and utility applications.

Key Advantages & Safety Features
  • Widely used for vehicle recovery and heavy-duty pulling
  • 12V DC powered, convenient and energy-efficient
  • High-torque DC motor for strong pulling force
  • Heavy-duty planetary gear transmission
  • Solenoid control box included for safe operation
  • Compact size, easy installation, and reliable performance
Technical Specifications

12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches

Model Rated line pull-single rope (lbs) performance voltage Motor (kw/hp) Drum diameter & length(mm) Total weight (kg)
THP-2000 2000 12V or 24V 1.1/1.0 31*72 6
THP-3000 3000 12V or 24V 1.1/.2 31*72 6.3
THP-3500 3500 12V or 24V 1.1/1.5 38*72 8.5
THP-4000 4000 12V or 24V 1.3/1.7 38*72 10
THP-4500 4500 12V or 24V 1.2/1.6 45*76.2 10
THP-6000 6000 12V or 24V 1.3/1.7 63.5*140 25
THP-9500 9500 12V or 24V 4.0/5.5 63.5*224 39
THP-12000 12000 12V or 24V 4.8/6.6 64*223.5 39
THP-20000 20000 12V or 24V 5.5/7.3 99*201.5 52

12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches

12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches

12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches

Manufacturer Profile

12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches

Industry Exhibitions & Global Presence
12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches 12v 24v Car Winch 4500lbs 6000lbs 12000lbs Electric Winches
