Specifications
Sling Type :
Wire Rope
Certifications :
CE, ISO
Lifting System :
electric motor
Cablematerial :
Steel
Max Lifting Height :
10-500M
Brand Name :
JCYC
Model Number :
KCD
Certification :
CE
Place of Origin :
CHINA
MOQ :
2 pcs
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
100 pcs / week
Delivery Time :
15 working days
Packaging Details :
Wooden
Warranty :
12 Months
Maximum Lifting Height :
100m As your requires
Capacity :
3-10ton
Motor :
6.5HP/4.8KW
Product name :
KCD Electric Winch Heavy Duty
Description
KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites
Product Overview

The KCD Electric Winch delivers heavy-duty lifting and pulling performance specifically designed for demanding construction applications.

Applications

The construction winch is widely used in the construction, metallurgy, mining, road and bridge, and lifting industries. It is suitable for:

  • Lifting heavy loads
  • Equipment installation
  • Material pulling
  • Pile driving
  • Cold-drawing steel bars
  • Other heavy-duty applications
Operating Conditions
  • Ambient Temperature: -10 °C to +40 °C
  • Relative Humidity: ≤ 85%
  • Altitude: Below 1,000 m
  • Working Environment: Free from fire, explosion hazards, and corrosive conditions
  • Power Supply: 380 V / 50 Hz / 3 Phase
  • Permissible Voltage Fluctuation: ± 5%

When the ambient temperature is below 0 °C, the lubricating oil should be preheated before starting.

Duty Rating

The winch is available with M4 or M5 duty ratings. If the operating duty is increased by one level during use, the rated line pull should be reduced by 20% accordingly.

Technical Specifications
Parameter Unit 0.25T 0.5T 1T 2T 3T 5T 10T 16T 20T
Lifting weight Ton 0.25 0.5 1 2 3 5 10 16 20
Lifting speed M/Min 8/16 8/16 8/16 8/16 8/16 8/16 8/16 8/16 8/16
Wire rope diameter mm 3.6 4.8 7.4 11 13 15.5 15.5 17.5 21.5
Wire diameter mm 0.22 0.22 0.5 0.6 0.7 0.7 0.7 0.7
Structure form 6*9 D-6*37+1 D-6*37+1 D-6*37+1 D-6*37+1 D-6*37+1 D-8*37+1 D-6*37+1 D-6*37+1
Lifting motor capacity kw 0.4 0.8/0.2/0.8 1.5/0.21/1.5 3/0.4/3 4.5/0.4/4.5 7.5/0.8/7.5 13/1.5/13 13/1.5/13 18.5
Motor speed R/Min 1380 1380 1380 1380 1380 1380 1380 1380 1380
Number of phase 3 3 3 3 3 3 3 3 3
Voltage V 380 380 380 380 380 380 380 380 380
Current An 1.25 2.4/0.72/2.4 4.3/0.72/4.3 7.6/1.25/7.6 11/2.4/11 18/2.4/7.11 30/4.3/30 30/4.3/30 41.7
Frequency Turn/Second 50 50 50 50 50 50 50 50 50
Product Images
KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites
Industry Exhibition
KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites KCD Electric Winch Heavy Duty Lifting And Pulling Performance For Construction Sites
