Specifications
Brand Name :
JCYC
Model Number :
HGS
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
$45.7-$158.6/per pc
Payment Terms :
T/T,L/C
Supply Ability :
5000 pcs/ per mouth
Delivery Time :
5-10 work days
Packaging Details :
1.Inner package: bubble film or stretch film. 2.Outside package: cartons or wooden cases.
Product name :
mini electric hoist
Power source :
Electric
Warranty :
1 Year
Sling type :
Wire Rope
After-sales service provided :
Online support
Lifting height :
6/12m
Max lifting weight :
1200kg
Application :
warehouse, home and so on
Type :
Stationary or Moveable
Voltage :
220v 230v 240v
Description

Mini Portable Electric Wire Rope Hoist

The mini electric hoist, also known as a civil electric hoist, is generally available in fixed type and trolley type. It is suitable for various applications and is designed to lift loads of up to 1,000 kg, especially ideal for lifting heavy items from the ground to upper floors of high-rise buildings.

Featuring a simple structure, easy installation, and a compact, lightweight design, the mini electric hoist is powered by a single-phase electric supply. Its design and manufacturing comply with international standards, ensuring safe and reliable operation. The motor cooling fins are made of cast iron, which improves heat dissipation and extends service life.

The lifting speed can reach 12 m/min, and the standard wire rope length is 12 meters (custom lengths available). The hoist is equipped with an advanced double-hook design, significantly increasing its lifting capacity. Powered by a 220V household power supply, it is widely used in residential applications, industrial production lines, and logistics handling.

Advantages & Features

  1. Compact and smart design, easy to operate and convenient to use.

  2. Automatic stop function when the limit stopper contacts the limit switch.

  3. Motor automatically stops if the wire rope is lifted in reverse.

  4. Hook operation supports dynamic loading and static loading modes.

  5. Operates on 220V household power supply.

  6. Plug-in power cable for simple and convenient use.

  7. 360° rotating hook for flexible and efficient operation.

Technical Parameters
Model Rated capacity kg

Rated vol

v

Lifting height

m

 Method of use Lifting speed m/min

Qty/CTN

pcs
HGS-PA200A 100/200 220/230/240 12/6

Single-hook

Double-hook

10

5

 2
HGS-PA250A 125/250 220/230/240 12/6

Single-hook

Double-hook

10

5

 2
HGS-PA500A 250/500 220/230/240 12/6

Single-hook

Double-hook

10

5

 2
HGS-PA600A 300/600 220/230/240 12/6

Single-hook

Double-hook

10

5

 2
HGS-PA700A 350/700 220/230/240 12/6

Single-hook

Double-hook

8

4

 2
HGS-PA1000A 500/1000 220/230/240 12/6

Single-hook

Double-hook

8

4

 1
HGS-PA1200A 600/1200 220/230/240 12/6

Single-hook

Double-hook

8

4

 1
HGS-PA200B 100/200 100/110/120 12/6

Single-hook

Double-hook

10

5

 2
HGS-PA400B 200/400 100/110/120 12/6

Single-hook

Double-hook

10

5

 2
