Standard Headroom Electric Wire Rope Hoist With Motor Trolley Designed Double Speed
Standard Headroom Electric Wire Rope Hoist With Motor Trolley Designed Double Speed
Specifications
Brand Name :
JCYC
Model Number :
SHSL-D
Certification :
CE&ISO
Place of Origin :
China
MOQ :
1 unit
Price :
USD negotiate per unit
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
500 pcs per month
Delivery Time :
10 -15 working days
Packaging Details :
Plywood case
Name :
Standard Headroom Electric Wire Rope Hoist
Usage :
Construction Hoist
Power Source :
Electric
Maximum Lifting Weight :
50t
Maximum Lifting Height :
30m
Lift Speed :
5/0.8m/mim
Description

Standard Headroom Electric Wire Rope Hoist With Motor Trolley Designed Double Speed

Standard Headroom Electric Hoist With Motor Trolley

They are applicable to various places such as factory, warehouse, stuff yard to lift goods, forbidden to use in flammable, explosive and corrosive environment.

Advantages

  • Double speed lifting motor for 1t-32t hoists; lifting motor with variable frequency for 32t-80t hoists
  • Electromagnetic disc brake, maintenance-free design
  • Lifting limit switch
  • Trolley is equipped with variable frequency motor, speed: 5-20m/min
  • Protection grade of motor: IP55, insulation grade: F
  • Hook set with safety buckles
  • Load lifting limiter

Product parameters

Capacity (kg) Lifting Height (m) Lifting Speed (m/min) Lifting Power (KW) Travelling Speed (m/min) Travelling Power (kw) Working Group (FEM/ISO) Traveling Working Group (FEM/ISO) I-beam B(mm)
2000 6 5/0.8 3.2/0.45 5/20 0.37 3M M6 2M M5 100-250
9 5/0.8 3.2/0.45 5/20 0.37 3M M6 2M M5 100-250
12 5/0.8 3.2/0.45 5/20 0.37 3M M6 2M M5 100-250
15 5/0.8 3.2/0.45 5/20 0.37 3M M6 2M M5 100-250
18 5/0.8 3.2/0.45 5/20 0.37 3M M6 2M M5 100-250
3200 6 5/0.8 3.2/0.45 5/20 0.37 2M M5 2M M5 100-250
9 5/0.8 3.2/0.45 5/20 0.37 2M M5 2M M5 100-250
12 5/0.8 3.2/0.45 5/20 0.37 2M M5 2M M5 100-250
15 5/0.8 3.2/0.45 5/20 0.37 2M M5 2M M5 100-250
18 5/0.8 3.2/0.45 5/20 0.37 2M M5 2M M5 100-250
5000 6 5/0.8 6.1/1 5/20 0.55 2M M5 2M M5 150-300
9 5/0.8 6.1/1 5/20 0.55 2M M5 2M M5 150-300
12 5/0.8 6.1/1 5/20 0.55 2M M5 2M M5 150-300
15 5/0.8 6.1/1 5/20 0.55 2M M5 2M M5 150-300
18 5/0.8 6.1/1 5/20 0.55 2M M5 2M M5 150-300
6300 6 5/0.8 6.1/1 5/20 0.55 1Am M4 2M M5 150-300
9 5/0.8 6.1/1 5/20 0.55 1Am M4 2M M5 150-300
12 5/0.8 6.1/1 5/20 0.55 1Am M4 2M M5 200-350
15 5/0.8 6.1/1 5/20 0.55 1Am M4 2M M5 200-350
18 5/0.8 6.1/1 5/20 0.55 1Am M4 2M M5 200-350
8000 6 5/0.8 9.5/1.5 5/20 0.75 3M M6 2M M5 150-300
9 5/0.8 9.5/1.5 5/20 0.75 3M M6 2M M5 150-300
12 5/0.8 9.5/1.5 5/20 0.75 3M M6 2M M5 150-300
15 5/0.8 9.5/1.5 5/20 0.75 3M M6 2M M5 150-300
18 5/0.8 9.5/1.5 5/20 0.75 3M M6 2M M5 150-300
10000 6 5/0.8 9.5/1.5 5/20 0.75 2M M5 2M M5 150-300
9 5/0.8 9.5/1.5 5/20 0.75 2M M5 2M M5 150-300
12 5/0.8 9.5/1.5 5/20 0.75 2M M5 2M M5 150-300
15 5/0.8 9.5/1.5 5/20 0.75 2M M5 2M M5 150-300
18 5/0.8 9.5/1.5 5/20 0.75 2M M5 2M M5 150-300
12500 6 4/0.6 12.5/2 5/20 0.75 1Am M4 2M M5 150-300
9 4/0.6 12.5/2 5/20 0.75 1Am M4 2M M5 150-300
12 4/0.6 12.5/2 5/20 0.75 1Am M4 2M M5 150-300
15 4/0.6 12.5/2 5/20 0.75 1Am M4 2M M5 150-300
18 4/0.6 12.5/2 5/20 0.75 1Am M4 2M M5 150-300
16000 6 4/0.6 16/2.6 5/20 0.75x2 2M M5 2M M5 250-350
9 4/0.6 16/2.6 5/20 0.75x2 2M M5 2M M5 250-350
12 4/0.6 16/2.6 5/20 0.75x2 2M M5 2M M5 250-350
15 4/0.6 16/2.6 5/20 0.75x2 2M M5 2M M5 250-350
18 4/0.6 16/2.6 5/20 0.75x2 2M M5 2M M5 250-350
20000 6 4/0.6 16/2.6 5/20 0.75x2 1Am M4 2M M5 250-350
9 4/0.6 16/2.6 5/20 0.75x2 1Am M4 2M M5 250-350
12 4/0.6 16/2.6 5/20 0.75x2 1Am M4 2M M5 250-350
15 4/0.6 16/2.6 5/20 0.75x2 1Am M4 2M M5 250-350
18 4/0.6 16/2.6 5/20 0.75x2 1Am M4 2M M5 250-350
8000 20 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
24 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
28 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
32 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
36 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
10000 20 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
24 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
28 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
32 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
36 8/1.3 16/2.6 5/20 0.75 2M M5 2M M5 150-300
12500 20 6.3/1 16/2.6 5/20 0.75 1Am M4 2M M5 150-300
24 6.3/1 16/2.6 5/20 0.75 1Am M4 2M M5 150-300
28 6.3/1 16/2.6 5/20 0.75 1Am M4 2M M5 150-300
32 6.3/1 16/2.6 5/20 0.75 1Am M4 2M M5 150-300
36 6.3/1 16/2.6 5/20 0.75 1Am M4 2M M5 150-300
