320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
320 Kg Explosion-Proof Pneumatic Balance Hoist With Variable Speed Control
Specifications
Brand Name :
JCYC, OEM
Model Number :
GTB
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 piece
Price :
599 USD
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
5000 per month
Delivery Time :
around 12 workdays
Packaging Details :
Standard Export Package
Product name :
Pneumatic Balance Hoist
Warranty :
1 Year
Power source :
Pneumatic
Usage :
Construction Hoist
Sling type :
Wire Rope
Capacity :
320kg
Lifting height :
2.8m
Lifting speed :
20-60 m/min
Description
Pneumatic Balance Hoist – The Ideal Material Handling Solution

A pneumatic balance hoist is an air-powered assisted lifting device. It uses compressed air as the power source and balances the load’s weight with the air pressure inside the cylinder through a transmission mechanism, enabling smooth lifting and lowering of heavy objects with minimal operator effort.

2. Advantages Compared with Electric Chain Hoists

  • High lifting and lowering speed
    The lifting and descending speed is typically 2–6 times faster than that of electric hoists.

  • “Floating” function for precise positioning
    Allows easy and accurate load positioning, making fine adjustments effortless.

  • Extremely high duty cycle
    Designed for continuous 24-hour operation without overheating.

  • Safer air-powered operation
    Uses compressed air as the power source, ensuring spark-free operation and higher safety, especially in hazardous environments.

  • Smooth and stepless speed control
    Driven by a screw transmission system, providing smooth, vibration-free lifting and lowering with infinitely variable speed control.

Technical Specifications
ItemsUnitSpecifications



Capacitykg0-60100160220320
SWLm1.41.82.31.9.11
Number of Wire Ropepc1111

1

Working MediumCompressed Air




Working Pressurempa0.630.630.630.630.63
Air ConsumptionM3/min0.18

0.21

0.210.250.3
Hose Fitting ThreadinPT 3/8PT 3/8PT 3/8PT 3/8PT 3/8
Hose Dia.mm1010121212
N.Wkg2127475265
Speed RangeRated Load SpeedUPm/min6035252015
Speed RangeNo load SpeedDownm/min2123252728
