Screw-In Offset Insulator INS081B Long Arm 230mm Electric Fence Fittings For Wood Post Wire 5mm
Screw-In Offset Insulator INS081B Long Arm 230mm Electric Fence Fittings For Wood Post Wire 5mm
Screw-In Offset Insulator INS081B Long Arm 230mm Electric Fence Fittings For Wood Post Wire 5mm
Screw-In Offset Insulator INS081B Long Arm 230mm Electric Fence Fittings For Wood Post Wire 5mm
Screw-In Offset Insulator INS081B Long Arm 230mm Electric Fence Fittings For Wood Post Wire 5mm
Screw-In Offset Insulator INS081B Long Arm 230mm Electric Fence Fittings For Wood Post Wire 5mm
Specifications
Conductor Material :
Stainless Steel
Insulation Material :
PP
MOQ :
1000pcs
Package :
300pcs/Case;228,000pcs/20'FCL
Application :
Electric Fence
Color :
Black or customized
Usage :
Electric Fencing
Name :
Electric Fence Insulators
Brand Name :
Terrui
Model Number :
INS081B
Certification :
ISO 9001
Place of Origin :
Shanghai
MOQ :
1000PCS
Price :
discuss
Payment Terms :
T/T
Supply Ability :
1,000,000PCS PER MONTH
Delivery Time :
in 10 days
Packaging Details :
Poly Bag & Carton
Description

Product Overview

The long arm multi-purpose offset insulator INS081B is designed to hold electric fence conductors well away from wooden posts and rails. With a total length of 230 mm split between a 55 mm plastic arm and a 55 mm galvanized steel screw, this fitting gives the line a clean offset gap that prevents animals from shorting the circuit against timber. It suits farms running mixed fence systems with both wire and tape conductors.

Key Features

  • Total 230 mm offset reach separates live conductors from post surfaces
  • 5.8 mm galvanized steel screw anchors the arm firmly into wood posts
  • Free-running ring accepts wire, poly wire and poly rope up to 5 mm
  • Impact-resistant plastic housing survives knocks, kicks and branch falls
  • Multi-purpose geometry works for top rails, gate posts and outrigger lines
  • Weighs only 49.5 g so it adds minimal load to the fence structure

Specifications

AttributeDetail
Item CodeINS081B
Product TypeLong Arm Multi-Purpose Offset Insulator
MaterialPP with galvanized steel screw
ColorBlack
Weight49.5 g
Total Length230 mm (plastic 55 mm, screw 55 mm)
Conductor CapacityWire, poly wire, poly rope up to 5 mm
Package300 pcs per case, 228,000 pcs per 20 ft container
Carton Size38 x 27 x 27 cm
PortShanghai or Ningbo

Where To Use

Commonly fitted to electrified wooden gate posts, permanent cattle fence corners and outrigger arms that keep conductors away from existing rails. The generous offset also keeps vegetation from touching the live line.

Installation Tips

Turn the screw into the post side so the arm extends across the fence plane, then thread the conductor through the end ring. Even spacing keeps wire sag uniform over long runs. Custom colors, packaging and materials can be arranged for large orders.
