Specifications
Place of Origin :
Shanghai, China
Brand Name :
Fineco
Model Number :
EM4372
Certification :
CE,MID
MOQ :
5 units
Price :
$34.00/units 5-199 units
Display Type :
Digital Only
Phase :
Three Phase
Measuring Energy Range :
0-999999.99-
Accuracy Class :
B & CL1.0
Output Voltage :
3*120/208V...3*240/415V
Operating Temperature :
-25 to +55
Dimensions :
90*104.5*60
Communication :
RS485 Modbus RTU
System wiring method :
3P4W,3P3W,1P2W
Voltage range :
3*120-240/208-415V
Application :
PV solar
OEM :
Allowed
Description

MID approved EM4372 5(65)A three phase
65A modbus kwh meter smart power analyzer
The EM4372 power quality meter is a standard four-module 72mm width, which can be used for single-phase two-wire/three-phase three-wire/three-phase four-wire power grids. The instrument provides real-time monitoring of A/B/C three phase Voltage(L-N,L-L), Amp, kW, kVA, kvar, PF, include maximum, minimum, average values. Phase angle, voltage phase sequence indications and Voltage asymmetry & current asymmetry. PT ratio& CT ratio selectable, THD up to 41th order for voltage& current and Maximum demand on Amp & kW& kVA.
The meter can also be used in a dual-power system to measure grid and generator charges; The instrument's RS485 communication port allows remote system connection to provide all parameters in real time. User can define modbus protocol.
Series Models:
Model
Nominal voltages
Function
EM4372
3×120/208~3×240/415V
● Compatible with LV,MV,HV applications
● System wiring method Y/Δ, Voltage L-L from 208V up to 415V
● More than 300 electrical parameters measured and displayed
● Harmonic analysis of voltage and current up to 41st order
● Phase sequence indication
● Voltage Asymmetry (Phase-Phase, Phase-Neural), Current Asymmetry
● Max & Min & Average &demand measure
● Load survey/profile, interval programmable
● Built-in RS485 communication port,modbus protocol
● Available the remote firmware upgrade of the instrument
3×220/380V 65A
3×230/400V 65A
3×240/415V 65A
2×S0+1×DO+1×RS485
3×230V 65A
3×400V 65A
