Specifications
Delivery Time :
30-45 work days
Model Number :
RM-F003
Material :
Metal,Steel bench and aluminum-plastic panel,Fiber glass with metal,stainless steel
Price :
/
Packaging Details :
Wooden packaging
Test cables :
Anti-drop double-loop sheathed, 3mm / 4mm interfaces
Supply Ability :
/
Payment Terms :
T/T
Training panel :
Double-layer spray-painted iron
Certification :
ISO9001/ISO45001/ISO14001,
Power outputs :
3-phase 380V, ±5V/±12V DC, 6-12V AC
Brand Name :
RUIMU
Weight :
<200Kg
Place of Origin :
Henan, China
Signal generator :
DDS, outputs sine, square & triangular waves
Description
Electrical and Electronic Basic Training Equipment Electronic Circuit Training Workbench
Comprehensive training system for mechanical and electronic majors in technical schools, featuring modular design for practical education in circuit analysis, electronics, and electrical engineering.
Product Overview
This advanced training device covers practical exercises for Circuit & Magnetic Circuit, Electronics, and Electrical Engineering courses. The system utilizes well-arranged hanging-box modules that enable easy function expansion for diverse training projects.
Available Practical Training Items
  1. Magnetization Characteristics
  2. Speed Control of DC Shunt Motor
  3. Swinburne's Test
  4. Brake Test on DC Shunt Motor
  5. OC & SC Tests on 1-Phase Transformer
  6. Brake Test on 3-Phase IM
  7. Regulation of Alternator
  8. PN Junction Diode
  9. Zener Diode
  10. Half-Wave Rectifier
  11. Full-Wave Rectifier
  12. CB Characteristics
  13. CE Characteristic
Key Features & Advantages
Modular Structure with Flexible Expansion
Independent hanging-box modules for magnetic circuit, electromagnetism, transformer and motor experiments. Modules can be added, removed or swapped to match different circuit, electronics and electrical engineering teaching demands.
High-Accuracy Multi-Function Power & Measurement System
  • Fully-digital multi-range AC/DC volt-ammeter and three-phase power meter for precise voltage, current, power and power-factor readings
  • DDS signal generator outputs sine, square & triangular waves; large LCD real-time displays frequency and waveform
  • Multiple isolated power outputs including 3-phase 380V, ±5V/±12V DC, 6-12V AC, with short-circuit safeguard
Robust Construction & Complete Safety Protection
Double-layer spray-painted iron training panel features anti-corrosion and anti-interference properties. Short-circuit protection on power terminals ensures safe experimental operation.
User-Friendly Quick-Connection Design
Equipped with anti-drop double-loop sheathed test cables (3mm / 4mm interfaces). Easy plug-and-play operation effectively reduces messy wiring and improves learning efficiency.
