Single Rail Electric Hoist Trolley 1T - 15T Chain Hoist Trolley Automated Material Handling System
Single Rail Electric Hoist Trolley 1T - 15T Chain Hoist Trolley Automated Material Handling System
Specifications
Model Number :
DGTC
Control :
Programmable, centralized/distributed options
Certification :
CE, ISO 9001:2015
Navigation :
Address code-based routing
MOQ :
1 Set
Delivery Time :
10-15 working days for stock, 25-30 days for production
Load Capacity :
1T to 15T
Payment Terms :
L/C,T/T
Price :
USD,250-500/SET
Gear Diameter :
130 mm to 350 mm
Supply Ability :
200 Sets per Month
Brand Name :
KOEO
Drive Type :
Electric, independent per trolley
Place of Origin :
Zhejiang, China
Power :
0.4 kW to 2.2 kW
Packaging Details :
KOEO branded plywood case with foam padding and moisture-proof wrapping, export-grade reinforced carton
Description

Electric Chain Hoist Single Rail Electric Trolley Automated Material Handling System

Single Rail Electric Trolley is an advanced, automated material handling system designed for efficient, flexible, and intelligent conveyance in industrial environments. Featuring independent drive units, 3D network mobility, and smart control systems, it is ideal for modern warehouses, manufacturing plants, and logistics centers. The Single Rail Electric Trolley is an advanced, automated material handling system designed for efficient, flexible, and intelligent conveyance in industrial environments. Featuring independent drive units, 3D network mobility, and smart control systems, it is ideal for modern warehouses, manufacturing plants, and logistics centers.

Electric Trolley Features
  • Independent Drive System – Each trolley operates autonomously for flexible and reliable transport.
  • Modular 3D Network – Includes tracks, side tracks, and turnplates for multi-directional material flow.
  • Multiple Control Modes – Supports centralized, distributed, or automated program-based control.
  • Smart On-Demand System – Vehicles can be requested via a random material supply system with address coding.
  • Automatic Sorting & Distribution – Equipped with ground-based address readers for seamless sorting operations.
Applications
  • Automated warehouses
  • Assembly lines
  • Logistics and distribution centers
  • Manufacturing plants
  • Airports and ports for cargo handling
Technical Specifications
  • Drive Type: Electric, independent per trolley
  • Control: Programmable, centralized/distributed options
  • Navigation: Address code-based routing
  • Compatibility: Customizable track layouts
  • Automation Level: Fully automatic or manual override
Specifications
Type Length (m) Power (kW) Orbit (kg) Gear diameter (φ) Output gear Application of the load Remarks
DGTC-0.75-130 0.75 0.4 9 130 M3 1T and less
DGTC-1.0-130 1.0 0.4 9 130 M3 1.5T and less
DGTC-1.25-150 1.25 0.4 9 150 M3 2T and less
DGTC-1.5-150 1.5 0.4 9 150 M3 2T and less
DGTC-1.8-150 1.8 0.4 9 150 M3 2T and less
DGTC-1.8-180 1.8 0.4 12 180 M3 3T and less
DGTC-2.0-180 2.0 0.4 12 180 M3 3T and less
DGTC-2.2-180 2.2 0.4 12 180 M3 3T and less
DGTC-2.0-200 2.0 0.75 12 200 M4 5T and less
DGTC-2.2-220 2.2 0.75 12 220 M4 5T and less
DGTC-2.5-220 2.5 0.75 12 220 M4 5T / 7.5T and less
DGTC-2.2-250 2.2 0.75 15 250 M4 5T / 7.5T and less
DGTC-2.5-250 2.5 0.75 15 250 M4 7.5T and less
DGTC-3.0-250 3.0 0.75 15 250 M4 10T and less
DGTC-2.5-280 2.5 0.75 22 280 M5 10T and less
DGTC-3.0-280 3.0 1.5 22 280 M5 10T and less
DGTC-3.5-280 3.5 1.5 22 280 M5 15T and less
DGTC-2.5-350 2.5 2.2–1.5 30 350 M5 15T and less
DGTC-3.0-350 3.0 2.2–1.5 30 350 M5 15T and less
DGTC-3.5-350 3.5 2.2–1.5 30 350 M5 15T and less
Why Choose Our Trolley System?
  • Increases operational efficiency
  • Reduces manual labor and human error
  • Adaptable to various industrial layouts
  • Scalable and easy to integrate
  • Low maintenance and energy-efficient
