Stringing Equipment Tools Stringing Block Five Wheel Conductor Pulleys
Item number | Model | Number of sheaves | Rated load (kN) | Weight (kg) | Features |
10151 | SHDN916 | 1 | 50 | 51 | MC MC nylon sheave |
10152 | SHSQN916 | 3 | 75 | 120 | |
10153 | SHWQN916 | 5 | 150 | 200 |
Configuration:
1.Maximum suitable conductor ACSR720.
2.Sheave dimension ( outside diameter× root diameter × sheave width) Φ916×Φ800×110(mm).
3.The middle sheave can be customized as cast steel sheave.
