ISO Approved 4.1kw 30KN 5T Electric Cable Puller
ISO Approved 4.1kw 30KN 5T Electric Cable Puller
ISO Approved 4.1kw 30KN 5T Electric Cable Puller
ISO Approved 4.1kw 30KN 5T Electric Cable Puller
ISO Approved 4.1kw 30KN 5T Electric Cable Puller
ISO Approved 4.1kw 30KN 5T Electric Cable Puller
Specifications
Brand Name :
LINGKAI
Model Number :
JJQ BELT TYPE
Certification :
ISO
Place of Origin :
NINGBO
MOQ :
1 sets
Price :
get the latest
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
200 sets/month
Delivery Time :
3-5 work days
Packaging Details :
wooden case
name :
belt type cable winch
power :
4.1kw
pulling force :
3,5.8 Ton
engine :
gas, diesel, electrical motor
weight :
100kgs
approved :
ISO
Description

30KN 5 TON BELT DRIVE VARIABLE SPEED WIRE ROPE TRACTION PULLING CABLE ELECTRIC POWER WINCH

Application: Wire Rope Electric Hoist Winch for Lifting is used in power transmission and distribution engineering, telephone construction tower erection, traction cable, line, hoisting tools , tower erection , pole setting,stringing wire in electrical power line construction, the electric winch is driven by a belt,effectively prevent the damage of overload, there are pros and cons and the speed of file, anti reverse gear moment to ensure construction safety.Winch can be modified as per requirement, such as changing curve capstan into straight even cylindrical shape and coming with steel rope.
Engine Powered Winch Type:
1. Diesel engine. 2. Gasoline engine. 3. Elecric Motor.

TECHNICAL DATA

Item number Model

Rotation

direction

 Gear

rotational

speed

()

Traction

speed

(m/min)

Tractive

force

(T)

Power

(KW)

Outline

size

(mm)

Weight

(kg)
09121

JJQ-3Q

6HP

Gasoline

engine

 corotation

Ⅰ

Slow

 9.0 4.0 3.0 4.04 840x450x500 82

Ⅱ

Fast

 16.0 6.6 1.8 780x450x500 85
reversal Reverse 7.5 3.3 No lifting
09121A

JJC-30

170F

Diesel

engine

 corotation

Ⅰ

Slow

 11.5 5.0 3.0 2.94 840x600x500 108

Ⅱ

Fast

 21.0 9.0 1.8
reversal Reverse 10.0 4.5 No lifting
09121B

JJD-30

3KW

Electromotor

 corotation

Ⅰ

Slow

 8.5 4.0 3.0 3.00 770x600x460 108

Ⅱ

Fast

 10.5 6.5 1.8
reversal Reverse 7.0 3.0 No lifting
09123

JJQ-50

9HP

Gasoline

engine

 corotation

Ⅰ

Slow

 6.5 4.0 5.0 6.61 1000x550x520 135

Ⅱ

Fast

 16.0 9.0 2.2
reversal Reverse 7.0 4.0 No lifting
09123A

JJC-50

6.6HP

Diesel

engine

 corotation

Ⅰ

Slow

 8.0 4.5 5.0 4.41 1000x750x600 168

Ⅱ

Fast

 19.0 11.0 2.3
reversal Reverse 10.0 5.5 No lifting
09123B

JJD-50

4KW

Electromotor

 corotation

Ⅰ

Slow

 5.5 3.5 5.0 4.00 1000x850x520 160

Ⅱ

Fast

 14.0 8.0 3.0
reversal Reverse 7.0 4.0 No lifting
09125

JJQ-80

13HP

Gasoline

engine

 corotation

Ⅰ

Slow

 5 3 8 9.60 1000x550x520 168

Ⅱ

Fast

 9 5 4.5
reversal Reverse 5 3 No lifting
09125A

JJC-80

10.5HP

Diesel

engine

 corotation

Ⅰ

Slow

 7 4 8

7.86		 1000x750x630 230

Ⅱ

Fast

 13 7.5 4
reversal Reverse 6.5 3.7 No liftin
