Specifications
Place of Origin :
Hebei, China
Brand Name :
Zhufeng
Model Number :
BVVB
Insulation Material :
PVC
Type :
LOW VOLTAGE
Application :
Electrical Appliance, Rv, and residential or commercial building branch circuit wiring
Conductor Material :
Copper
Jacket :
PVC
Product name :
Copper conductor PVC insulated and sheathed flat cable
Conductor :
high quality Oxygen-free copper
Specification :
1.5mm²/2.5mm²/4mm²/6mm²
Rated voltage :
450/750V
Standard :
GB 5023.4-1997,JB8734.2-1998
Certificate :
ISO,CCC,CE,RoHS
MOQ :
500 meters
Price :
$1.99 - $3.99/meters
Description
Product Description
Insulation Material PVC 2core 1.5mm2/2.5mm2/4mm2/6mm2 Flat Twin Electrical Wires and Cables
Insulation Material PVC 2core 1.5mm2/2.5mm2/4mm2/6mm2 Flat Twin Electrical Wires and Cables
BVVB cable wire characteristics

PVC insulated wire is not only simple in structure and convenient in use, but also has good electrical insulation, physical and mechanical properties, non-flammability, compression resistance, chemical resistance, impact resistance and moisture resistance.

The laying temperature of the wire is not less than 0℃, and the maximum working temperature is allowed for a long time (70℃). The current transmission capacity is large.

BVVB wires produced by Zhufeng Cable Daming Co., Ltd also have the following advantages:

1. good insulation:
PVC keeps the original good insulation characteristics of PE, and the insulation resistance is further increased. The tangent of the dielectric loss Angle is very small and is not affected by temperature.

2. no delay combustibility:
PVC has a good flame retardant type, its flame retardant value of more than 40, so it is widely used in fire protection
applications.

3. Better mechanical properties:
Due to the establishment of new chemical bonds between macromolecules, the hardness, stiffness, wear resistance and impact resistance of PVC have been improved, so as to make up for the shortcomings of PE vulnerable to environmental stress and cracking.

4. Chemical resistance:
PVC has strong acid and alkali resistance and oil resistance (resistance to concentrated hydrochloric acid, concentration of 90% sulfuric acid, concentration of 60% nitric acid, and concentration of 20% sodium hydroxide).
Specification
Product name
flat Copper conductor PVC insulated and sheathed power cable
Insulation
PVC
Model
BVVB
Temperature
70°C
Rated voltage
300/500V 450/750V
Standard
JB/T 8734.2
Specification
2*1.5mm²/2*2.5mm²/2*4mm²/2*6mm²
Sheath
PVC
Application
It is commonly used for open wiring, electrical equipment and building indoor wiring
Conductor
copper
Insulation Material PVC 2core 1.5mm2/2.5mm2/4mm2/6mm2 Flat Twin Electrical Wires and Cables
Pure Oxygen-Free Copper Conductor to Ensure Conductivity.
Insulation Material PVC 2core 1.5mm2/2.5mm2/4mm2/6mm2 Flat Twin Electrical Wires and Cables
Environmentally-Friendly PVC Material with Excellent Insulation Performance, Scratch Resistance, Abrasion Resistance, GreatToughness.
