3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification
3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification
3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification
3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification
Specifications
Brand Name :
HENGFENGYOU
Model Number :
SCB10
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
200-200000/piece
Payment Terms :
LC T/T
Supply Ability :
5000 pieces/year
Delivery Time :
15 DAYS
Packaging Details :
wooden case
Phase :
Three
Coil Number :
Autotransformer
Packing :
wooden box
Standard :
CQC,SGS,ISO
Rated voltage :
6.3KV
Coil Structure :
Toroidal
HS code :
8504340000
Description

Cast Resin Dry Type Power Transformer 11kv

SC(B)10 Series Resin Insulation Dry-type Transformer is made of high-quality silicon

steel sheets, cast epoxy resin, and with intelligentized temperature control system, which will alarm

and trip when it fault or overheat.So it is advantageous in safety, low loss, low noise, fire-proof, low

partial discharge and high anti short-circuit capacity.Also it can be connected with computer, to make

it centralized management and supervise.Due to above features, SC(B) Series Resin Insulation Dry-type

Transformer widely apply to power supply and distribution system, such as hotel, airport, tall building,

commercial center, hospital, resident area, subway, power industrial, ship , offshore drilling platform

and so on.

3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification

Product Series SC9,SC10,SC(B)9,SC(B)10,SC(B)11
Rated capacity 30~2500kVA
Rated HV 6kV ~10 kV
Rated LV 0.4kv
Frequency 50Hz or 60Hz
Cooling methods AN AF
Tapping Range: ±5%
±2x2.5%
Phase Single Phase or Three Phases
Connection Symbol Yyn0 or Dyn11
class of insulation endurance F grade.Insulation level: LI75AC35/LI 0AC5.
class of safety protection IP20,IP23 shell ,or custom according to customer's require
Main performance index of temperature controller

Working temperature: - 10 ℃ ~ + 55 ℃

Power supply: AC220V 10%, 50Hz

Measurement range: 0~200C

Output signal contact capacity: AC220V, 3A
Function Serial communication (rs-485), transmission distance up to 1200 meters

3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification

3000kVA Dry Type Epoxy Distribution Power Transformer ISO9001 Certification
