Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Blue PET Polyester Film Battery Termination Tape
Specifications
Brand Name :
LiangYi
Model Number :
LY-ZZ-30B
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 rolls per day
Delivery Time :
5-8 work days
Packaging Details :
Tapes in plastic bags then in cartons
Color :
Blue
Backing Material :
PET Film
Width :
Customizable
Length :
Customizable
Thickness :
0.03mm
Adhesive :
Acrylic
Description

Product Description:
The LY-ZZ-30B is a high-performance PET (Polyester) termination tape specifically engineered for the demanding environments of modern battery manufacturing. As a critical component in battery insulation and fixing, this tape provides reliable protection and stability for energy storage solutions.

Key Features:

1.Strong Electrolyte Resistance: Formulated with a special adhesive that withstands prolonged exposure to aggressive electrolytes without degradation, ensuring long-term reliability inside the battery cell.

2.Non-Discoloring: Maintains its original color and integrity over time. It resists yellowing or fading caused by chemical reaction or heat, preventing contamination risks.

3.High Adhesion: Provides a secure hold for winding applications, preventing unwinding or shifting during battery assembly and operation.

4.Thin & Conformable: The PET backing offers excellent conformability for wrapping around sharp corners and irregular surfaces of battery cells.

Applications:

Power Battery Insulation: Used for outer wrapping and insulation protection of prismatic and cylindrical power batteries.

Lithium Battery Cell Winding: Ideal for securing the ends of cell windings (jelly rolls) to prevent telescoping and internal short circuits.

Electrode & Core Fixing: Applied for the fixation of electrodes and cores during the assembly process of lithium-ion batteries.



Blue PET Polyester Film Battery Termination Tape


Test items/Method

Test unit

Test Specifications

Test method

Total thickness

μ

30±3

GB/T 7125-2014

Backing material

μ

20±2

GB/T 7125-2014

Adhesion to Steel

(20min)N/25mm

3-7

GB/T 2792-2014

Temperature Resistance

℃

-20~110

GB/T 32368-2015

Electrolyte Resistance

85℃/4h: No residue, no color fade.

Color

Blue

Visual Check

Specification

Custom sizes available (slitting & rewinding).
