Phoenix Contact 500V 24 A Spring Terminal Block with 4 Connections Feed-through Terminal Block Connector
Phoenix Contact 500V 24 A Spring Terminal Block with 4 Connections Feed-through Terminal Block Connector
Phoenix Contact 500V 24 A Spring Terminal Block with 4 Connections Feed-through Terminal Block Connector
Phoenix Contact 500V 24 A Spring Terminal Block with 4 Connections Feed-through Terminal Block Connector
Specifications
Depth on NS 35/7,5 :
47.5 mm
Brand Name :
Phoenix Contact
Model Number :
UT 2,5-QUATTRO
Certification :
UL,CSA,EAC...
Place of Origin :
DE
MOQ :
50
Price :
$0.64-$0.99
Payment Terms :
T/T
Supply Ability :
800000
Delivery Time :
3-5work days
Packaging Details :
carton box
number of connections :
4
Minimum order quantity :
50 pcs
voltage :
500V
nominal current :
24 A
Width :
5.2 mm
End cover width :
2.2 mm
Depth on NS 35/15 :
55 mm
Height :
65.4 mm
Depth :
46.9 mm
Color :
gray
Packing unit :
50pcs
Description
Phoenix Contact Spring Terminal Blocks Connector 3044542 UT 2,5-QUATTRO
Feed-through terminal block, nominal voltage: 500 V, nominal current: 24 A, number of connections: 4, connection method: Screw connection, Rated cross section: 2.5 mm², cross section: 0.14 mm² - 4 mm², mounting type: NS 35/7,5, NS 35/15, color: gray
Specifications
Product Type Multi-conductor terminal block
Product Family UT
Area of Application Railway industry, Machine building, Plant engineering, Process industry
Number of Connections 4
Number of Rows 1
Potentials 1
Overvoltage Category III
Degree of Pollution 3
Rated Surge Voltage 6 kV
Maximum Power Dissipation 0.77 W
Nominal Cross Section 2.5 mm²
Rated Cross Section AWG 12
Connection Method Screw connection
Screw Thread M3
Tightening Torque 0.5 ... 0.6 Nm
Stripping Length 9 mm
Conductor Cross-section Range 0.14 mm² ... 4 mm²
Cross Section AWG Range 26 ... 12
