Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Hot Heating 5-120mm 1.5D Elbow Forming Machine
Specifications
Brand Name :
HEI YAN
Model Number :
HYW
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
2 sets per month
Delivery Time :
60 working days
Packaging Details :
wooden packing or according to the customer's requests
Material :
CS And AS
Elbow Size :
15-1020mm
Elbow Thickness :
2-70mm
Elbow Radius :
1D 1.5D
Heating System :
Induction Heating
Heating Power :
80-1000KW
High Light :
elbow making machine, elbow hot forming machine
Description

Hot Heating Elbow Making Equipment 5 - 120mm Wall Thickness Elbow Forming Machine

materials used by this Pipe Elbow Machine Induction Hot Heating Machine Elbow Mandrel Machine:

seamlsee steel pipe, welded steel pipe and rolled steel pipe.

The equipment can produce the elbows in varieties:

outer size: 25mm ~ 1420mm;

thickness: 5mm ~ 120mm; angle: 45 , 60 , 90 , 180 and the angle required by user.

Gost Standard Elbow Mandrel Forming Machine material:

carbon seamless steel,20 G, A106B, A106Welded pipe:235 B,345 B, X42, X52, X60, X70.

Hot Heating 5-120mm 1.5D Elbow Forming MachineHot Heating 5-120mm 1.5D Elbow Forming Machine

Elbow size outer diameter Φ25mm(1″)~Φ1420mm(56″)
Wall thickness 5~120mm
Bent diameter ≤3
Bent degree 22.5°,45°,90°,135° etc.
Hydraulic cylinder 2/4sets

Machine composition

1. machine base/frame
2. Main cylinder and supporting plate
3. pushing plate
4. front supporting plate
5. loading table
6. induction coils and adjusting device
7. medium frequency power supply
8. electrical control system
9. auxiliary equipment: hydraulic machine/ stamping moulds/pipe end cutting machine/quality testing machine

Hei Yan Group owns HYW Series of steel products line including Pipe Elbow Machine Induction Hot Heating Machine Elbow Mandrel Machine Hot Forming Machine Making Elbow,steel pipe expanding machine, steel pipe bending machine,hydraulic tee forming machine,bevelling machine. The HY Series machinery are designed for customer's point and needs.
Hydraulic Hot Forming Elbow Machine Hot Forming Machine Making Elbow is our traditional products with year's experience.The machine can process carbon steel, alloy steel etc and it can make OD114mm, OD159mm,OD219mm,OD426mm,OD630mm etc.

Hot Heating 5-120mm 1.5D Elbow Forming MachineHot Heating 5-120mm 1.5D Elbow Forming MachineHot Heating 5-120mm 1.5D Elbow Forming Machine
