7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion
7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion
7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion
7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion
7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion
7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion
Specifications
Brand Name :
CHENGUANG FSP
Model Number :
7270
Certification :
ISO9001
Place of Origin :
China
Product Name :
Common Silicone Rubber for Molding and Extrusion
Apperance :
Milky white, no obvious extraneous matter
Density :
1.22±0.05g/cm3
Tensile Strength :
≥7.0MPa
Elongation at Breakage :
≥250%
Tear Strength :
≥20kN/m
Description

Common Silicone Rubber for Molding and Extrusion

7.0Mpa Good Mechanical Properties HTV Silicone Rubber Raw Materials for Molding and Extrusion

BASIS INFORMATION

The properties of this product are a result of using high-quality raw materials and special ingredients. It exhibits excellent resistance to both high and low temperatures, in addition to possessing favourable physical, mechanical, and electrical properties. Moreover, this rubber is highly transparent and has strong physical and mechanical attributes. When manufacturing, molded silicone rubber employs vulcanizator “Double 2, 5”, while extruded silicone rubber uses vulcanizator “Double 2, 4”. Consequently, it is ideal for producing electrical equipment, as well as various wire, cable, tube, and strip components.

7.0Mpa HTV Silicone Extrusion Silicone Rubber Raw Materials For Molding And Extrusion

CHARACTERISTICS

1. High Temperature Resistance: Common silicone rubber can withstand high temperatures, making it suitable for use in applications where other rubbers would degrade or fail.

2. Excellent Flexibility: Silicone rubber is very flexible, allowing it to be easily molded into various shapes and sizes.

3. Good Electrical Insulation: Silicone rubber is a good electrical insulator, making it useful in electrical and electronic applications.

4. Good Resistance to Weathering: Silicone rubber has excellent resistance to weathering, including UV radiation, ozone, and extreme temperatures.

5. Non-reactive: Silicone rubber is non-reactive to most chemicals, which makes it suitable for use in applications that require resistance to chemicals or solvents.

SPECIFICATION

Model Properties Unit Parameters
7270
Appearance
Milky-white no obvious extraneous
matter
Density
g/cm3
1.22±0.05
Hardness
Shore A Points
70±2
Tensile Strength
MPa≥
7.0
Elongation at
Breakage
% ≥
250
Tension Set
% ≤
14
Tear Strength
kN/m ≥
20
Volume Resistivity
Ω.cm
1.0X1014
Dielectric Strength
kv/mm≧
18

Physical and Mechanical Properties are based on first vulcanization data,Electrical Properties are drawn from
second vulcanization data.
first vulcanization condition for test piece: 175℃*5min
Second vulcanization condition for test piece: 200℃*2h
Vulcanizator: 80% DMDBH,quantity added 0.65% *
*All our product are manufactured at ISO9001:2000 registered facilities.

PACKING AND SHIPPING

This product can be transported using standard methods of transportation. It is essential to keep the products away from rain and sun exposure, as well as fire and heat sources. Additionally, they should not come into contact with the air and must be kept away from strong acids, strong alkalis, metallic lead, and their compounds. The packaging must also be sealed, and care should be taken while loading and unloading to avoid any damage to the packaging or containers. Any unused products should be sealed and stored to prevent contamination.
