Specifications
Brand Name :
CHENGUANG FSP
Model Number :
DHS-9330
Certification :
FDA / LFGB / SGS
Place of Origin :
China
Product Name :
High Transparency Silicone Rubber
Elongation at Breakage :
700%
Tear Strength :
≥20kN/m
Payment Terms :
T/C, T/T
Tension Set :
≤8%
Dielectric Strength :
≧22kv/mm
Description

Food Grade High Transparency Silicone Rubber

High Transparent 8Mpa Silicone Rubber 9330 Series 700% Elongation for Bake Wares

PROPERTIES


High transparent silicone rubber has several properties that make it a versatile and desirable material for various applications. Some of the notable properties include:

1. Transparency: High transparent silicone rubber is crystal clear, allowing for high clarity and visibility. This property makes it an ideal option for applications that require a clear view, such as lenses, windows, and displays.

2. Electrical insulation: High transparent silicone rubber has exceptional electrical insulation properties that make it an excellent option for electronic components and devices. It prevents electrical current from leaking or arcing between different components, ensuring safety.

3. Water and moisture resistance: High transparent silicone rubber is highly resistant to water and moisture, making it perfect for applications that require water-resistant properties, such as underwater cameras and other devices.

4. Non-toxicity: High transparent silicone rubber is non-toxic, making it safe for use in products that may come into contact with food or medical applications.

5. UV resistance: High transparent silicone rubber is highly resistant to UV radiation, making it an ideal option for outdoor applications, such as solar panels and outdoor lighting fixtures.

6. Easy-to-clean: High transparent silicone rubber is easy to clean and can be sanitized easily, making it perfect for use in medical and food-related applications.

SPECIFICATION


Model
DHS-9330
DHS-9340
Appearance

Translucent,no obvious extraneous matter

Density (g/cm3)

1.07±0.04

1.13±0.04

Hardness (Shore A Points)
32±2

40±2

Tensile Strength (MPa≥)
8.0

9.0

Elongation at Breakage (%)
700

600

Tension Set (% ≤)

8

8
Tear Strength (kN/m ≥)
20
35

Volume Resistivity (Ω.cm)

1.0X1016

Dielectric Strength (kv/mm≧)

22

Linear Shrinkage Rate after the first vulcanization 3.0-3.6%

Physical and Mechanical Properties are based on the first vulcanization data,Electrical Properties are drawn from the second vulcanization data.
The first vulcanization condition for test piece: 175℃×5min;The second vulcanization condition for test piece: 200℃×2h
Vulcanizator: Liquid DMDBH, quantity added 0.65%

ABOUT US


Founded in 2002, we are a modern management enterprise integrating R&D, Production, Sales and Service, headquartered in Chengdu, Sichuan Province, China.

●We currently has 10 sets of fluoroelastomer precompound and compound production lines with total production capacity over 8,000 tons/year. We also have a 100,000 class purification workshop with 3 production lines specializing in the production of fluoroelastomer compound for smart wearable devices, annual production capacity over 3,000 tons/year.

●We always insists on bringing in the world's leading technology and gathering high-tech talents. We have gathered a large number of local and foreign high-end technical talents in the fields of production, R&D, and sales. To support our business, we built specialized in R&D laboratory, smart wearable engneering center and laboratory, etc.

● We are strictly controlled under IATF 16949:2016, GB/T 28001-2011,GB/24001-2004. Our products are widely used in the automotive industry, semiconductor, consumer electronics, aerospace, chemical and other fields, and are also irreplaceable key materials in the cutting-edge defense industry. Our products are sold to many domestic provinces and cities, and also exported to more than 30 countries and regions such as Europe, America, South Korea, Japan, Southeast Asia, the Middle East and etc...
