Specifications
Brand Name :
LG
Model Number :
LP133WQ1-SPB1
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
$48 or Negotiation for mass order
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
resolution :
2560*1600pixels
style :
30PIN IPS
brightness :
350CD/M2
color :
1.07B
contrast ratio :
1300 :1
working life :
30K Hours
Type :
lcm
Size :
23.8inch
Lamp type :
WLED
Voltage :
10.0V
Description
LG 23.8inch Desktop Lcd Monitor LM238WR3-SSC1 3840*2160Pixels 185PPI 350cd/M2 30PIN


LM238WR3-SSC1 (Alias: LM238WR3 (SS)(C1)) is a 23.8" diagonal a-Si TFT-LCD display panel product from LG Display Co., Ltd. (hereafter called LG Display), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: Wide Color Gamut, sRGB, 3-side boderless, WLED Backlight, Reverse I/F, 10 bit, Matte , 3-side Borderless, Reverse type. Based on its features, Einklcd recommend that this model be applied to Desktop Monitor etc. According to the information stored in Einklcd this model mass production on Q3, 2020, Now this model is discontinued. We inputted this model's specification on Jan 21 2022 for the first time, and the latest update on Dec 10 2024. If you want to embed the LCM in your future product, Einklcd strongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail of LM238WR3-SSC1. The production status marked on Einklcd.com is for reference only and should not be used as the basis for the user's decision making.


Brand
LG Display
Model P/N
LM238WR3-SSC1
Diagonal Size
23.8"
Panel Type
a-Si TFT-LCD, LCM
Resolution
3840(RGB)×2160, UHD 185PPI
Pixel Format
RGB Vertical Stripe
Active Area
525.658(W)×295.704(H) mm
Bezel Opening
-
Outline Dim. 536.42(H)×314.02(V) ×12.9(D) mm Treatment Antiglare (Haze 25%), Hard coating (3H)
Luminance 350 cd/m² (Typ.) Contrast Ratio 1300:1 (Typ.) (TM)
View Direction Symmetry Response Time 14 (Typ.)(G to G)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Operating Mode IPS, Normally Black, Transmissive
Support Color 1.07B 100% NTSC Light Source WLED , 30K hours , W/O Driver
Weight 1.61/1.69Kgs (Typ./Max.) Designed For LG 23.8inch Industrial LCD Display Desktop LCD Monitor with 3840x2160 Pixels and 350cd/m2 Brightness
Frame Rate 60Hz Touch Panel Without
Interface Type eDP (4 Lanes) , HBR2 (5.4G/lane) , 30 pins Connector
Power Supply 10.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C


LG 23.8inch Industrial LCD Display Desktop LCD Monitor with 3840x2160 Pixels and 350cd/m2 Brightness
