8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics
Specifications
Brand Name :
auo
Model Number :
C080VW02 V0
Certification :
Rohs,CE,FCC
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
T/T,W,Western Union,MoneyGram
Supply Ability :
3000pcs per week
Delivery Time :
4-5 working day
Packaging Details :
Industrial packing
Quality :
Brand new Original
Package :
Original industrial packing
resolution :
480*800
style :
60PIN IPS
brightness :
400 CD/M2
color :
262k
contrast ratio :
800 :1
working life :
10k hours without driver
Description

  • Panel Brand

    AUO

    Panel Model

    C080VW02 V0

    Panel Size

    8.0"

    Panel Type

    a-Si TFT-LCD, LCM

    Resolution

    800(RGB)×480 , WVGA

    Pixel Format

    RGB Vertical Stripe

    Display Area

    175.2(W)×105.12(H) mm

    Bezel Opening

    177.0(W)×106.92(H) mm

    Outline Size

    186.5(W)×117.22(H) mm

    Surface

    Antiglare

    Brightness

    400 cd/m² (Min.)

    Contrast Ratio

    300:1 (Typ.) (TM)

    Viewing Angle

    60/60/40/60 (Typ.)(CR≥10)

    Display Mode

    TN, Normally White, Transmissive

    Best View on

    6 o'clock

    Response Time

    15/20 (Typ.)(Tr/Td)

    Display Colors

    262K

    Lamp Type

    WLED , 10K hours , Without Driver

    Frequency

    60Hz

    Touch Screen

    Without

    Panel Weight

    180±18g

    Application

    Signal Interface

    Parallel RGB (1 ch, 6-bit) , 60 pins , Connector

    Input Voltage

    3.3/9.8/15/-10V (Typ.)(VCC/AVDD/VGH/VGL)

    Environment

    Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²)

  • 8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics8'' Car LCD Display Screen with 480*800 Resolution and 400 CD/M2 Brightness by AU Optronics

All Origianl product will be send to customer after full test one by one.

  • Spec details can be send to you via email,please contact us.
